Matrix 424, 832, 832+ Installation Manual

4.1.7 Central Monitoring Options

Telephone Numbers
Communication Protocols
Group Reporting to CMS
Zone Attributes
Programmable Send Options
Test Call
Telephone Line Monitoring
Telephone Connection
Digital Communicator
Lightning Protection

4.1.8 Other

Software Support
Memory Event Log

4.2 Minimum Installation Requirements

In addition to the main alarm panel (Matrix 424, 832 or 832+), and any detectors or sensors, at least one
keypad is required. This can be an LCD or ICON keypad. One keypad MUST be set to ID-1. This is the
minimum requirement.
A maximum of 6 devices can be attached to the Matrix bus (see also Section 1.9 on page 4: Cabling Rules for
the Matrix Bus). The following table shows the maximum number of each device type allowable, whilst at the
same time remembering that only 6 devices in total (apart from on-board zone expander) can be on the bus
at any one time.
Page 46
9 telephone numbers shared with pager, Pyronix PC format and
digital communication formats
Contact ID, BSIA Fast Format, Pyronix PC, Pager, MX Voice
Events sent to 1 number only
Events sent to 2 numbers
Events sent to first number with backup of second number
Chime, Test, Mask, Double knock, Normally open
In Disarmed Mode, In Arm Modes (A, B, C and D), Restorals,
Intruder, PAs, Fire,
Confirmed, Omit (Bypass)
Programmable in days, hours and minutes
Yes – with status indication
Allows other telephone on the line
Analogue line
Heavy duty lightning protection 6.75kV/125Amps
UDL programming software
Pyronix MX-MON monitoring software to be used with:
a) Modem + Pyronix format
b) RC12/RC112 + Contact ID
300 events with time and date
Log deletion cannot be allowed either accidentally or on
purpose.
Log reaction time is more than 30 days and the clock will not
change more than + / - 10 min over 1 year at 20c
Maintenance, Open/Close, Medical,
