Matrix 424, 832, 832+ Installation Manual
Battery Capacity
Plastic Enclosure 2.8 to 7Ah
Metal Enclosure (832+) 2.8 to
BAT Terminal Protection Short & reverse
Low Battery Detect Level 10.7V ± 0.2V
Battery Cut-off Level 10.4V ± 0.2V
* NOTE - Italy: To conform with CEI79, the maximum battery size is limited to 12Ah.
# NOTE - Italy: To conform with CEI79 the operational temperature must be
4.3.2 Keypads, Proximity Reader & Additional Expanders
ICON KEYPAD
Supply Voltage
Supply Current
Min. brightness setting 40mA @ 13.8V
Max. brightness setting 60mA @ 13.8V
Operating temperature
Dimension
WIRELESS ZONE EXPANDER (MX-RIX8DW)
Supply Voltage
Quiescent Current
Transmitting Current
All LEDs on current
Transmission Frequency
Transmission Method
Transmission Range
Programming LEDs
Supported Zones
Supported Keyfobs
PROXIMITY READER (MX-PROX)
Supply Voltage
Supply Current
Operating temperature
Dimension
LOCAL PLUG-ON ZONE EXPANDER (MX-IX16)
Supply Voltage
Supply Current
Zone Loop Current
Zone Activation Resistance
TRANSISTOR OUTPUT EXPANDER (MX-ROX8T)
Supply Voltage
Supply Current
Outputs
Max. Switching Voltage
Max. Switching Current
Page 48
17Ah*
(with MX-BATT)
13.8V typical (9-16V range)
0 to +50ºC (32 to 122ºF)
75 x 127 x 29 mm
13.8V typical (9-16V range)
100mA
135mA
120mA
868MHz, FM Transceiver
Narrow Band
Fully Encrypted Rolling Code Transmission Method
300m Free Space
11
8
32
13.8V typical (9-16V range)
Max. 90mA @ 13.8V
-10 to +50ºC (14 to 122ºF)
85 x 85 x 21 mm
13.8V typical (9-16V range)
15mA ± 5% @ 13.8V
0.54mA – Max.
See main control panel data
13.8V typical (9-16V range)
45mA ± 5% @ 13.8V
8 Open collectors
12Vdc
500mA
Operational
Plastic Case 0 to +40ºC (32 to 104ºF)
Metal Case (832+) -10 to +55ºC (14 to
Storage -20 to +60ºC (-4 to 140ºF)
Maximum Humidity
Plastic Case N/A
Metal Case (832+) 93% Rh
LCD KEYPAD
Supply Voltage
Supply Current
Min. brightness setting 20mA @ 13.8V
Max. brightness setting 80mA @ 13.8V
Operating temperature
Dimension
USER KEY FOB (KF4DW)
Battery
Battery Life
Buttons
Progammable Actions
Transmission Frequency
Colour
Casing
VOICE MODULE (MX-VOICE)
Supply Voltage
Supply Current
Number of messages
Message length
REMOTE MX-RIX WITH ZONE ANALYSER
Supply Voltage
Supply Current
Zone Loop Current
Zone Activation Resistance
RELAY OUTPUT EXPANDER (MX-ROX8R)
Supply Voltage
Supply Current
Outputs
Max. Switching Voltage
Max. Switching Current
131ºF)#
0 to +40ºC (32 to 104ºF).
13.8V typical (9-16V range)
0 to +50ºC (32 to 122ºF)
139 x 127 x 29 mm
3V 360mAhr
Up to 1 year
4
6
868MHz, FM Transceiver
Narrow Band
Fully Encrypted Rolling Code
Black
2mm Polycarbonate
13.8V typical (9-16V range)
Max. 25mA @ 13.8V
8
up to 7 sec.
12V typical (9-16V range)
25mA ± 5% @ 13.8V
0.54mA – Max.
See main control panel data
13.8V typical (9-16V range)
225mA ± 5% @ 13.8V
8 NO/NC contacts
30V
3A
RINS918-6
