Led Diagnostics; Terminal Identification - Altronix eFlow6NV Installation Manual

Power Supply/Charger
Red (DC) Green (AC/AC1)
ON ON
ON OFF
OFF ON
OFF OFF
Power Distribution Module
Green (AC) Power Distribution Module Status
ON Normal operating condition.
OFF No power output.
Power Supply/Charger
Terminal Legend Function/Description
Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral (non power-limited)
L, N
(Fig. 1a, pg.5).
– DC + 12VDC or 24VDC nominal @ 6 amp continuous output (non power-limited output) (Fig. 1h, pg. 5).
Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
Supervised normally closed from an FACP output circuit (power-limited input) (Fig. 1d, pg. 5).
NO, GND RESET FACP interface latching or non-latching (power-limited) (Fig. 1e, pg. 5).
+ AUX – Auxiliary power-limited output rated @ 1 amp (unswitched) (power-limited output) (Fig. 1f, pg. 5).
AC Fail Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
NC, C, NO when AC power is present. Contact rating 1 amp @ 30VDC (power-limited) (Fig. 1b, pg. 5).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC
Bat Fail
power is present. Contact rating 1 amp @ 30VDC. A removed battery is reported within 5 minutes.
NC, C, NO
Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 5).
– BAT + Stand-by battery connections. Maximum charge current 1.54 amp (non power-limited) (Fig. 1g, pg. 5).
Power Distribution Module
Terminal Legend
PD8/PD8CB
1P to 8P
1N to 8N
- 4 -
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.

Terminal Identification:

Terminal Identification:
Terminal Legend
PD16W/PD16WCB
1P to 16P
1N to 16N

LED Diagnostics:

Function/Description
Positive DC power outputs.
Negative DC power outputs.
eFlow6NV Series
