Altronix eFlow6NV Installation Manual page 16

Models Include:
Model
eFlow6NV,
eFlow6N8V, eFlow6N8DV,
eFlow6N16V, eFlow6N16DV
eFlow6NXV,
eFlow6NX8V, eFlow6NX8DV,
eFlow6NX16V, eFlow6NX16DV
The eFlow6NV series power supply/chargers convert a 220VAC, 50/60Hz input, to a 12VDC or 24VDC output.
Battery
7AH
12AH
40AH
65AH
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 1.54 amp.
• Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous
with no interruption.
Red (DC) Green (AC/AC1) Power Supply Status
ON ON
ON OFF
OFF ON
OFF OFF
Installing Company: _________________________________ Service Rep. Name: ___________________________________________________
Address: _______________________________________________________________________ Phone #: _______________________________
Refer to the eFlow Power Supply/Chargers Installation Guide: IIeFlow6NV Series, Rev. 6NVRP052213 for complete
instructions. This sheet is to be removed, framed and posted next to the unit.
Rev. 6NVRP052213
Power Supply/Chargers Operating Guide
Input
220VAC,
50/60Hz
2.1 amp
Stand-by Specifications:
Burg. Applications
4 hr. Stand-by/15 min. Alarm
0.4 amp/6 amp
1 amp/6 amp
6 amp/6 amp
6 amp/6 amp
LED Diagnostics:
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Output
12VDC 24VDC
6 amp 6 amp
Overview:
Fire Applications
24 hr. Stand-by/5 min. Alarm
N/A
0.3 amp/6 amp
1.2 amp/6 amp
1.5 amp/6 amp
Auxiliary Power-Limited
Output (unswitched)
1 amp
Access Control
Applications Stand-by
10 Mins./6 amp
25 Mins./6 amp
Over 4 Hours/6 amp
Over 4 Hours/6 amp
Ripple
Voltage
910mV
