Led Diagnostics; Terminal Identification - Altronix MaxFit FE Series Installation Manual

Red (DC)
ON
ON
OFF
OFF
Red (Bat)
ON
OFF
Terminal
Function/Description
Legend
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral.
L, N
Do not use terminal marked [G] (Fig. 1a, pg. 4).
+ DC – Refer to MaxFitFE Series Configuration Chart, pg. 2 (Fig. 1h, pg. 4).
Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
Supervised normally closed from an FACP output circuit (power-limited input) (Fig. 1d, pg. 4).
NO, GND
FACP interface latching or non-latching (power-limited) (Fig. 1e, pg. 4).
RESET
+ AUX – Auxiliary Power-Limited output rated @ 1A (unswitched) (Fig. 1f, pg. 4).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
AC FAIL
Relay normally energized when AC power is present.
NC, C, NO
Contact rating 1A @ 30VDC (power-limited) (Fig. 1b, pg. 4).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
BAT FAIL when DC power is present. Contact rating 1A @ 30VDC.
NC, C, NO A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 4).
Stand-by battery connections.
+ BAT –
Maximum charge current 1.54A (non power-limited) (Fig. 1g, pg. 4).
Battery
7AH
12AH
40AH
65AH
Only these configurations can be utilized in ULC-S319 installations.
*
MaxiFit3FE/MaxFit5FE/MaxFit7FE Expandable Power Systems Installation Guide

LED Diagnostics:

Green (AC/AC1)
ON
OFF
ON
OFF
Battery Status
Normal operating condition.
Battery fail/low battery.

Terminal Identification:

Stand-by Battery Specifications:
MaxFit3FE
10 Mins./6A
30 Mins./6A*
Over 4 Hours/6A*
Over 4 Hours/6A*
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery is supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
MaxFit5FE and MaxFit7FE
5 Mins./10A
30 Mins./10A*
Over 2 Hours/10A*
Over 4 Hours/10A*
- 5 -
