eFlow3NV Series
Power Supply/Chargers
Models Include:
eFlow3NV/eFlow3NXV
- 2A @ 12VDC or 24VDC Output
eFlow3N4V/eFlow3NX4V
- 2A @ 12VDC or 24VDC
- Four (4) Fused Outputs
eFlow3N4DV/eFlow3NX4DV
- 2A @ 12VDC or 24VDC
- Four (4) PTC Outputs
Installation Guide
Rev. 3NVRP122713
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix eFlow3NV Series
Summary of Contents for Altronix eFlow3NV Series
- Page 1 Series Power Supply/Chargers Models Include: eFlow3NV/eFlow3NXV - 2A @ 12VDC or 24VDC Output eFlow3N4V/eFlow3NX4V - 2A @ 12VDC or 24VDC - Four (4) Fused Outputs eFlow3N4DV/eFlow3NX4DV - 2A @ 12VDC or 24VDC - Four (4) PTC Outputs Installation Guide More than just power.
- Page 2 Overview: Altronix eFlow3NV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a 12VDC or 24VDC nominal output (see Power Supply Configuration Reference Chart and Specifications). eFlow3NV Series Power Supply Configuration Reference Chart: Nominal DC Outputs...
-
Page 3: Specifications
Prevents deep battery discharge. • Overvoltage protection. Visual Indicators: Fuse Ratings: • Green AC Power LED indicates 220VAC present. • Refer to eFlow3NV Series Power Supply • AC input and DC output LED indicators. Configuration Reference Chart, pg. 2. Additional Features: Battery Backup: •... -
Page 4: Maintenance
[Trigger EOL Shutdown] (Fig. 1e, pg. 5). 12. For Access Control Applications: mount tamper switch (Altronix Model TS112 or equivalent) at the top of the enclosure. Slide tamper switch bracket onto the edge or the enclosure approx. 2” from the right side (Fig. -
Page 5: Terminal Identification
DC Trouble (low battery, loss of battery or when 95% of the stand-by battery has been depleted). Connect the circuit to the Batt Fail relay contacts to an appropriate input of a Burglar Alarm or Access Control Panel. The following figure shows the circuitry needed for local annunciation. eFlow3NV Series Installation Guide - 5 -... -
Page 6: Power Distribution Module(S)
1P-4P Power Outputs, Board 1N-4N Common Outputs (Factory Installed) Fig. 3b - PD4CB - Power Distribution Board DC Output to devices From Power Supply 1P-4P Power Outputs, Board 1N-4N Common Outputs (Factory Installed) - 6 - eFlow3NV Series Installation Guide... - Page 7 Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing. 7AH Rechargeable batteries are the largest batteries that can fit in this enclosure. A UL Listed external battery enclosure must be used if using 12AH, 40AH or 65AH batteries. eFlow3NV Series Installation Guide - 7 -...
- Page 8 Distribution (power- limited) DC Outputs (power-limited) Battery Connections (non power-limited) Fig. 5a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 8 - eFlow3NV Series Installation Guide...
- Page 9 Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing. 12AH Rechargeable batteries are the largest batteries that can fit in this enclosure. A UL listed external battery enclosure must be used if using 40AH or 65AH batteries. eFlow3NV Series Installation Guide - 9 -...
- Page 10 Distribution (power-limited) DC Output (power- limited) Battery Connections (non power-limited) Fig. 7a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 10 - eFlow3NV Series Installation Guide...
- Page 11 (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) eFlow3NV Series Installation Guide - 11 -...
- Page 12 (31.8mm) 1.1” (27.9mm) 1.1” (27.9mm) 1.375” 1.5” 1.5” (34.9mm) (38.1mm) (38.1mm) 1.125” (28.6mm) 2.0” (50.8mm) 2.0” (50.8mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.1” (27.9mm) 1.75” (44.5mm) 1.5” 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) - 12 - eFlow3NV Series Installation Guide...
-
Page 13: Appendix A - Ul Listed Compatible Devices
PR-1** R-20T** PR-2* R-24T** PR-3* R-10E** System Sensor System Sensor EOLR-1 R-14E** R-10T** R-20E** R-14T** R-24E** * Compatible only with eFlow3NV, eFlow3NXV, eFlow3N4V, eFlow3NX4V. ** Compatible only when unit is set for 24VDC. eFlow3NV Series Installation Guide - 13 -... - Page 14 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 15 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. IIeFlow3NV Series G22U MEMBER eFlow3NV Series Installation Guide...
- Page 16 3.5A 960mV eFlow3NXV, eFlow3NX4V, eFlow3NX4DV Overview: The eFlow3NV series power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a 12VDC or 24VDC output. Stand-by Specifications: Burg. Applications Fire Applications 4 hr. Stand-by/ 24 hr. Stand-by/...
