Led Diagnostics; Terminal Identification - Altronix WayPoint104 Installation Manual

8. Connect devices to be powered to terminals marked [– DC +] (Fig. 1h, pg. 4).
For auxiliary device connection this output will not be affected by Low Power Disconnect or
Output Disconnect. Connect device to terminals marked [+ AUX –] (Fig. 1f, pg. 4).
9. For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result
in the loss of the output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel
type. Connect battery to terminals marked [– BAT +] (Fig. 1g, pg. 4). Use two (2) 12VDC batteries connected
in series for 24VDC operation (battery leads included) Use batteries - Casil CL1270 (12V/7AH) batteries or
UL recognized BAZR2 batteries of an appropriate rating.
10. Connect appropriate signaling notification devices to AC FAIL & BAT FAIL (Fig. 1b, pg. 4) supervisory
relay outputs.
11. To delay AC reporting for 2 hrs. set dip switch [AC Delay] to OFF position (Fig. 1c, pg. 4).
To delay AC reporting for 1 min. set dip switch [AC Delay] to ON position (Fig. 1c, pg. 4).
12. To enable Output Disconnect set DIP switch [Shutdown] to ON position (Fig. 1c, pg. 4).
To disable Output Disconnect set DIP switch [Shutdown] to OFF position (Fig. 1c, pg. 4).
13. Trigger terminals are end of a line resistor supervised (10k ohms). Opening or shorting trigger terminals
will cause [DC] output to shutdown (Fig. 1d, pg. 4).
14. Place a jumper for non-latching output. A momentary short on these terminals resets output latching
[Trigger EOL Shutdown] (Fig. 1e, pg. 4).
15. Upon completion of wiring secure enclosure door with latches and optional lock.
WARNING: When installing in a non-restricted service area use lock or other fastened means on door
latches. This installation should be made by qualified service personnel and should conform to the
National Electrical Code and all local codes.
Red (DC)
ON
ON
OFF
OFF
Terminal
Function/Description
Legend
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral(non power-limited)
L, G, N
(Fig. 1a, pg. 4).
– DC + WayPoint102: 12VDC @ 10A continuous output (Non power-limited output).
(Fig. 1h, pg. 4) WayPoint104: 24VDC @ 10A continuous output (Non power-limited output).
Trigger EOL Trigger inputs can be normally open, normally closed from an output circuit
Supervised (power-limited input) (Fig. 1d, pg. 4).
NO, GND
Trigger input latching or non-latching (power-limited) (Fig. 1c, pg. 4).
RESET
Auxiliary power-limited output rated @ 1A (unswitched) (power-limited output)
+ AUX –
(Fig. 1f, pg. 4).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
AC Fail
Relay normally energized when AC power is present.
NC, C, NO
Contact rating 1A @ 30VDC (power-limited) (Fig. 1b, pg. 4).
Indicates low battery condition, e.g. connect to alarm panel.
Bat Fail Relay normally energized when DC power is present. Contact rating 1A @ 30VDC.
NC, C, NO A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 4).
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
– BAT +
(Fig. 1g, pg. 4).
WayPoint DC

LED Diagnostics:

Green (AC/AC1)
ON
OFF
ON
OFF

Terminal Identification:

Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
- 3 -
