Led Diagnostics; Terminal Identification - Altronix SMP10WP12 Installation Manual

Red (DC)
ON
ON
OFF
OFF
Terminal Legend
L, G, N
– DC +
– BAT +
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 6 -

LED Diagnostics:

Green (AC)
ON
OFF
ON
OFF

Terminal Identification:

Function/Description
Connect 115VAC to these terminals: L to Hot, N to Neutral, G to ground.
12VDC @ 10A continuous supply current.
Stand-by battery connections. Maximum charge rate 0.7A.
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery is supplying power.
No DC output. Short circuit or thermal overload condition.
No DC output. Loss of AC. Discharged or no battery present.
SMP10WP12 Installation Guide
