Unit should be tested at least once a year for the proper operation as follows:
FACP Supervision:
Normally Open Input:
Normally Closed Input:
FACP Signal Circuit Input:
Output Voltage Test:
Battery Test:
LED
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
Red (Bat)
ON
OFF

Access Power Controller LED Diagnostics:

LED
LED 1- LED 8 (Red) Output relay(s) energized.
Trg (Green)
- 6 -

Maintenance:

To ensure proper connection and operation of the Fire Alarm disconnect
hookup. Please follow the appropriate procedure below:
Placing a short between terminals marked [T] and [+ INP] will trigger the
Fire Alarm Disconnect. Remove the short to reset.
Remove the wire from terminal marked [INP –] will trigger the Fire Alarm
Disconnect. Replace the wire to terminal marked [INP –] to reset.
It is necessary to trigger the Fire Alarm System.
In all of the above scenarios the green TRG LED of the ACM8s will
illuminate. All outputs selected for Fire Alarm Disconnect will activate
releasing locking devices.
Note: All outputs [OUT 1 - OUT 8] must be in a normal (de-energized)
condition prior to testing. When the unit is configured for Normally Open
(Fig. 13, pg. 18) or Normally Closed (Fig. 15, pg. 18) latching operation,
it is necessary to reset the Fire Alarm Disconnect by activating the
Normally Closed reset switch.
Under normal load conditions, the DC output voltage should be checked
for proper voltage level (Power Supply Board Stand-by Battery
Specifications, pg. 8).
Under normal load conditions check that the battery is fully charged, check
specified voltage at the battery terminals and at the board terminals marked
[+ BAT –] to ensure that there is no break in the battery connection wires.
Note: AL400XB2V, AL600XB220 and AL1012XB220 Power Supply
Board maximum charge current is 0.7A.
AL1024XB2V Power Supply Board maximum charge current is 3.6A.
Expected battery life is 5 years; however, it is recommended to change
batteries within 4 years or less if necessary.

Power Supply Board LED Diagnostics:

Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output. Short circuit or thermal overload condition.
No DC output. Loss of AC. Discharged battery.
Battery Status
Normal operating condition.
Battery fail/low battery.
ON
FACP input triggered (alarm condition).
Maximal11V / Maximal33V / Maximal55V / Maximal75V / Maximal77V Access Power Controllers (Fused) Installation Guide
OFF
Output relay(s) de-energized.
FACP normal (non-alarm condition).
