eFlow104NK8QP Series
Networkable Dual Output
Power Supply/Chargers
Models Include:
eFlow104NK8QP
- 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output.
- Eight (8) fuse protected outputs.
- Management interface for eFlow power supply/charger.
- Two (2) network controlled Form "C" relays.
- Built-in Charger for sealed lead acid or gel type batteries.
eFlow104NKA8D
- 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output.
- Eight (8) Class 2 power-limited PTC protected outputs.
- Management interface for eFlow power supply/charger.
- Two (2) network controlled Form "C" relays.
- Built-in Charger for sealed lead acid or gel type batteries.
Installation Guide
Rev. eFlow104NK8QP-072420
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eFLOW eFlow104NKA8D Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altronix eFLOW eFlow104NKA8D Series

  • Page 1 eFlow104NK8QP Series Networkable Dual Output Power Supply/Chargers Models Include: eFlow104NK8QP - 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output. - Eight (8) fuse protected outputs. - Management interface for eFlow power supply/charger. - Two (2) network controlled Form “C”...
  • Page 2 Dual input design allows power to be steered from two (2) fac- tory installed independent low voltage 12 or 24VDC Altronix power supplies to eight (8) independently controlled fuse (eFlow104NK8QP) or PTC (eFlow104NK8DQP) protected outputs. Networkable power distribution module facilitates monitoring, reporting, and control of the supervised DC power supply/charger over the network.
  • Page 3: Specifications

    Specifications: Inputs: Fire Alarm Disconnect: eFlow104NB: eFlow104NB: • 120VAC, 60Hz, 4.5A. • Supervised Fire Alarm disconnect (latching or LINQ8PD/LINQ8PDCB: non-latching) 10K EOL resistor. Operates on a • 24VDC from eFlow104NB. normally open (NO) or normally closed (NC) trigger. • 12VDC from VR6 voltage regulator. LINQ8PD(CB): Outputs: •...
  • Page 4: Installation Instructions

    Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction. Product is intended for indoor use only. 1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure.
  • Page 5: Maintenance

    13. Installation of tamper switch: Mount UL Listed tamper switch (Altronix model TS112 or equivalent) at the top of the enclosure. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 6a, pg. 8).
  • Page 6: Led Diagnostics

    LED Diagnostics: eFlow104NB Power Supply/Charger Red (DC) Green (AC/AC1) Power Supply Status Normal operating condition. Loss of AC. Stand-by battery is supplying power. No DC output. Loss of AC. Discharged or no stand-by battery. No DC output. LINQ8PD and LINQ8PDCB Networkable Power Distribution Module Flash Codes Description Charge/Discharge current working properly.
  • Page 7 Ethernet: LAN or laptop connection enables LINQ8PD(CB) programming and RJ45 status monitoring. Laptop connection enables LINQ8PD(CB) for Network setup and factory restore J USB via Altronix dashboard. Battery Fail Relay3 - Programmable for Battery Fail reporting or Tamper. NC, C Contact rating 1A @ 30VDC.
  • Page 8 Fig. 4 - eFlow104NK8(D)QP Tamper Switch Power Output Factory wired to LINQ8PD(CB) and VR6 (non power-limited) eFlow104NB Power Supply Battery Output Factory wired to LINQ8PD(CB) (non power-limited) AC FAIL NC C NO NC C NO BAT FAIL Factory wired supervisory connections (power-limited) FACP Interface (power-limited) 24VDC from...
  • Page 9 Network Setup: –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Altronix Dashboard USB Connection: The USB connection on the LINQ8PD(CB) is used for Network. When connected to a PC via the USB cable the LINQ8PD(CB) will receive power from the USB port allowing programming of the LINQ8PD(CB) prior to being connected to the power supply.
  • Page 10: Browser Setup

    A dialog box will display “New network settings will take effect after the server is rebooted”. Click OK. Browser Setup: When not using the Altronix Dashboard USB connection for the initial Network setup the LINQ8PD(CB) needs to be connected to any DC power supply(ies) or eFlow power supply(ies) being monitored prior to programing.
  • Page 11 Notes: eFlow104NK8(D)QP Installation Guide - 11 -...
  • Page 12 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIeFlow104NK8(D)QP...
