Specifications - Altronix eFlow6NV Installation Manual

The eFlow6NV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a
12VDC or 24VDC nominal output (see Power Supply Configuration Reference Chart and Specifications).
eFlow6NV Series Power Supply Configuration Reference Chart:
Nominal DC Outputs
[DC]
eFlow6NV
10.0-
13.2
eFlow6NXV
eFlow6N8V
10.0-
13.2
eFlow6NX8V
eFlow6N8DV
9.78-
13.2
eFlow6NX8DV
eFlow6N16V
10.0-
13.2
eFlow6NX16V
eFlow6N16DV
9.78-
13.2
eFlow6NX16DV
European Conformity
Battery
7AH
12AH
40AH (for eFlow6NXV refer to Fig. 8, pg. 10)
65AH (for eFlow6NXV refer to Fig. 8, pg. 10)
Input:
• 220VAC (working range 198VAC - 256VAC), 50/60Hz.
Output:
• For output voltage and supply current refer to eFlow6NV
Series Power Supply Configuration Reference Chart, pg. 2.
• Auxiliary output rated @ 1 amp (unswitched).
• Overvoltage protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 1.54 amp.
• Automatic switch over to stand-by battery when AC fails.
Transfer to stand-by battery power is instantaneous with
no interruption.
Fire Alarm Disconnect:
• Supervised Fire Alarm disconnect (latching or
non-latching) 10K EOL resistor. Operates on a normally
open (NO) or normally closed (NC) trigger.
Supervision:
• AC fail supervision (form "C" contacts).
• Battery fail and presence supervision (form "C" contacts).
- 2 -
[AUX]
20.19- 10.03- 20.19-
26.4 13.2 26.4
20.19- 10.03- 20.19-
26.4 13.2 26.4
20.0- 10.03- 20.19-
26.4 13.2 26.4
20.19- 10.03- 20.19-
26.4 13.2 26.4
20.0- 10.03- 20.19-
26.4 13.2 26.4
Stand-by Specifications:
Overview:
6 2.1A 5A/250V 10A/32V 910
6 2.1A 5A/250V 10A/32V 910
6 2.1A 5A/250V 10A/32V 910
6 2.1A 5A/250V 10A/32V 910
6 2.1A 5A/250V 10A/32V 910
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
0.4 amp/6 amp
1 amp/6 amp
6 amp/6 amp
6 amp/6 amp

Specifications:

Supervision (cont'd):
• Low power shutdown. Shuts down DC output terminals
if battery voltage drops below 71-73% for 12V units
and 70-75% for 24V units (depending on the power
supply). Prevents deep battery discharge.
Fuse Ratings:
• Refer to eFlow6NV Series Power Supply Configuration
Reference Chart, pg. 2.
Visual Indicators:
• Green AC Power LED indicates 220VAC present.
• AC input and DC output LED indicators.
Additional Features:
• Short circuit and overload protection.
• Unit is complete with power supply, enclosure,
battery leads and cam lock.
Enclosure Dimensions (approximate H x W x D):
eFlow6NV, eFlow6N8V, eFlow6N8DV,
eFlow6N16V, eFlow6N16DV:
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
eFlow6NXV, eFlow6NX8V, eFlow6NX8DV,
eFlow6NX16V, eFlow6NX16DV:
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm)
N/A 1
PD8 8
PD8CB 8
PD16W
16
2 - PD8
PD16WCB
16
2 - PD8CB
Fire Applications
24 hr. Stand-by/
5 min. Alarm
N/A
0.3 amp/6 amp
1.2 amp/6 amp Over 4 Hours/6 amp
1.5 amp/6 amp Over 4 Hours/6 amp
– – –
3
– – –
3
2.5A – –
3
2.5A – –
3
– 2A –
3
– 2A –
3
2.5A – –
3
2.5A – –
3
– 2A –
3
– 2A –
3
Access Control
Applications
Stand-by
10 Mins./6 amp
25 Mins./6 amp
