Altronix eFlow6NV Installation Manual page 7

Fig. 5 - eFlow6NV configuration
Door
Wire
Strap
(from
Enclosure
to Door)
eFlow6NV Series
Green
Lead
L
(ground)
220VAC
G
power mains
AC1
NC
C
Battery and AC
NO
Supervision
NC
Circuit
C
NO
AC
DC
AC DELAY
SHUTDOWN
Battery
Connections
--- BAT +
Optional Rechargeable
Stand-by Battery
CAUTION: When power supply board is set for 12VDC use only one (1) 12VDC stand-by battery.
Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing.
7AH Rechargeable batteries are the largest batteries that can fit in this enclosure.
An external battery enclosure must be used if using 12AH, 40AH or 65AH batteries.
Switch Detail
Switch On - 12V
(refer to Fig. 3a, 3b, 4a or 4b
Switch Off - 24V
for board configuration pg. 6)
OFF --- 24V
ON --- 12V
ON
--- DC +
Sentrol
model # 3012
Tamper Switch
or equivalent
(Not Included)
PD8/PD8CB PD16W/
PD16WCB
DC Output to devices*
Optional Rechargeable
Stand-by Battery
Edge of
Enclosure
Enclosure
to Access Control
Panel or
U.L. Listed
Reporting
Device
- 7 -
