Power Supply/Charger Boards
Installation Guide
Models Include:
eFlow3NBV
- 12VDC or 24VDC @ 2A
eFlow4NBV
- 12 or 24VDC @ 4A
eFlow6NBV
- 12 or 24VDC @ 6A
eFlow102NBV
- 12VDC @ 10A
eFlow104NBV
- 24VDC @ 10A
Rev. EFNBV-061418
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eFLOW Series and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix eFLOW Series

Summary of Contents for Altronix eFLOW Series

  • Page 1 Power Supply/Charger Boards Installation Guide Models Include: eFlow3NBV - 12VDC or 24VDC @ 2A eFlow4NBV - 12 or 24VDC @ 4A eFlow6NBV - 12 or 24VDC @ 6A eFlow102NBV - 12VDC @ 10A eFlow104NBV - 24VDC @ 10A More than just power. Rev.

  • Page 2: Table Of Contents

    Table of Contents: Overview pg. 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications pg.

  • Page 3: Overview

    Overview: Altronix eFlowNBV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a 12VDC or 24VDC output . Specifications: Output Voltage (Current) Maximum Altronix Input Rating Aux. Output Charge 12VDC 24VDC Model Nuber 220VAC 50/60Hz (unswitched)

  • Page 4: Stand-By Specifications

    Stand-by Specifications: eFlow3NBV: Burg. Applications Fire Applications Access Control Battery 4 hr. Stand-by/15 min. Alarm 24 hr. Stand-by/5 min. Alarm ApplicationsStand-by 0 .4A/2A – 1 .5 Hours/2A 12AH 1A/2A 0 .3A/2A 3 .5 Hours/2A 40AH 2A/2A 1 .2A/2A Over 4 Hours/2A 65AH 2A/2A 1 .5A/2A...

  • Page 5: Installation Instructions

    Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction . Product is intended for indoor use only . 1 . Mount the eFlowNBV power supply/charger in desired location/enclosure (mounting hardware included) . Use metal standoffs for the bottom mounting holes to provide sufficient grounding for the board .

  • Page 6: Wiring

    Wiring: Use 18 AWG or larger for all low voltage power connections . Note: Take care to keep power-limited circuits separate from non power-limited wiring (220VAC, Battery) Maintenance: Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level .
  • Page 7 Altronix is not responsible for any typographical errors . 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . MEMBER...
