Power Supply/Chargers
Installation Guide
Models Include:
eFlow102NV/eFlow102NXV
- 10A @ 12VDC
eFlow102N8V/
eFlow102NX8V
- 10A @ 12VDC
- Eight (8) Fused Outputs
eFlow102N16V/
eFlow102NX16V
- 10A @ 12VDC
- Sixteen (16) Fused Outputs
Rev. 102NVRP052213
Installing Company: ________________ Service Rep. Name: ______________________________________
Address: ___________________________________________________ Phone #: _____________________
eFlow102N8DV/
eFlow102NX8DV
- 10A @ 12VDC
- Eight (8) PTC Protected Outputs
eFlow102N16DV/
eFlow102NX16DV
- 10A @ 12VDC
- Sixteen (16) PTC Protected Outputs
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix eFlow102NV
Summary of Contents for Altronix eFlow102NV
- Page 1 Power Supply/Chargers Installation Guide Models Include: eFlow102NV/eFlow102NXV - 10A @ 12VDC eFlow102N8V/ eFlow102N8DV/ eFlow102NX8V eFlow102NX8DV - 10A @ 12VDC - 10A @ 12VDC - Eight (8) Fused Outputs - Eight (8) PTC Protected Outputs eFlow102N16DV/ eFlow102N16V/ eFlow102NX16DV eFlow102NX16V - 10A @ 12VDC...
- Page 2 Overview: Altronix eFlow102NV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input to a 12VDC nominal output (see Power Supply Configuration Reference Chart and Specifications). eFlow102NV Series Power Supply Configuration Reference Chart: Nominal DC Outputs [DC] [AUX]...
-
Page 3: Specifications
3. Measure output voltage before connecting devices. This helps avoiding potential damage. 4. Connect devices to be powered: a. For eFlow102NV/eFlow102NXV connect devices to terminals marked [– DC +] (Fig. 1h, pg. 5). b. For other Power Distribution Models connect devices to be powered to terminal pairs 1 to 8 marked [1P &... -
Page 4: Maintenance
[Trigger EOL Shutdown] (Fig. 1e, pg. 5). 11. For Access Control Applications: mount tamper switch (Altronix model TS112 or equivalent) at the top of the enclosure. Slide tamper switch bracket onto the edge or the enclosure approx. 2” from the right side (Fig. -
Page 5: Terminal Identification
PD16W/PD16WCB 1P to 8P 1P to 16P Positive DC power outputs. 1N to 8N 1N to 16N Negative DC power outputs. Fig. 1 - eFlow102NV Board configuration AC FAIL BAT FAIL AC DELAY SHUTDOWN 5A 250V 1 min. enable TRIGGER EOL... -
Page 6: Power Distribution Module(S)
9 10 11 12 13 14 15 16 outputs outputs protected protected outputs outputs From From Power Power Supply Supply Board Board (Factory (Factory Installed) Installed) For continuous protection against risk of fire replace fuses with same type and rating. 3.5A 250V - 6 - eFlow102NV Series... - Page 7 7AH Rechargeable batteries are the largest batteries that can fit in this enclosure. An external battery enclosure must be used if using 12AH, 40AH or 65AH batteries. * Outputs are non power-limited: eFlow102NV, eFlow102N8V, eFlow102N16V. Outputs are power-limited: eFlow102N8DV, eFlow102N16DV.
- Page 8 NEC Power-Limited Wiring Requirements for eFlow102NV Models: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits.
- Page 9 Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing. 12AH Rechargeable batteries are the largest batteries that can fit in this enclosure. An external battery enclosure must be used if using 40AH or 65AH batteries. eFlow102NV Series - 9 -...
- Page 10 (non power-limited) Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation * Outputs are non power-limited: eFlow102NXV, eFlow102NX8V, eFlow102NX16V. Pull back Outputs are power-limited: Solid Copper external jacketed Conductors eFlow102NX8DV, eFlow102NX16DV. shield approx. 1/2”. - 10 - eFlow102NV Series...
- Page 11 Enclosure Dimensions (BC300): eFlow102NV, eFlow102N8V, eFlow102N8DV, eFlow102N16V, eFlow102N16DV 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75” 0.75” (31mm) 11.0” (31mm) (19mm)
- Page 12 0.91” (23.114mm) (23.114mm) 1.5” 1.5” (38.1mm) (38.1mm) 2.0” 15.5” (50.8mm) (393.7mm) 2.0” (50.8mm) 5.0” 5.0” (127.0mm) (127.0mm) 0.79” 1.1” (20.06mm) 1.25” 1.25” (27.94mm) (31.75mm) (31.75mm) 1.75” (44.45mm) 1.5” 4.615” 4.615” 1.5” (38.1mm) (117.22mm) (117.22mm) (38.1mm) - 12 - eFlow102NV Series...
-
Page 13: Appendix A - Compatible Devices
Appendix A - Compatible Devices A.1 Four (4) Wire Smoke Detectors Table A-1 below lists four (4) wire smoke detectors compatible with eFlow102NV output. Alarm System Sensor Smoke Stand-by Detector Type Current Detector/Base Current (mA) (mA) B112LP Base 0.12 B114LP... - Page 14 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 15 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIeFlow102NV Series G25R eFlow102NV Series...
- Page 16 2.1A – 760mV eFlow102NXV, eFlow102NX8V, Flow102NX8DV, eFlow102NX16V, eFlow102NX16DV Overview: The eFlow102NV series power supply/chargers convert a 220VAC, 50/60Hz input to a 12VDC output. Stand-by Specifications: Burg. Applications Fire Applications 4 hr. Stand-by/ 24 hr. Stand-by/ Access Control Battery 15 min.
