RS-232C Host Types

Three RS-232C hosts are set up with their own parameter default settings
Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal sets the defaults listed below.
These defaults take precedence over standard defaults. So if you select Fujitsu RS-232C,
then select the standard defaults, the Fujitsu defaults still apply.
Parameter
Transmit Code ID
Data Transmission Format
Suffix
Baud Rate
Parity
Hardware Handshaking
Software Handshaking
Serial Response Time-out
Stop Bit Select
ASCII Format
Beep On <BEL>
RTS Line State
*In the Nixdorf Mode B, if CTS is Low, scanning is disabled. When CTS is High, the user can scan
bar codes.
Table 3-2. Terminal Specific RS-232C
ICL
Yes
Data/Suffix
CR (1013)
9600
Even
RTS/CTS
Option 3
None
9.9 Sec.
One
8-Bit
Disabled
High
Parameter Menus
(Table
Fujitsu
Mode A/Mode B
Yes
Data/Suffix Data/Suffix
CR (1013) CR (1013)
9600
None
None RTS/CTS
None
2 Sec.
One
8-Bit
Disabled
Low *Low = No data to
3-2).
Nixdorf
Yes
9600
Odd
Option 3
None
9.9 Sec.
One
8-Bit
Disabled
send
3-13
