Cyclone
Code Type Option Value
RSS Family
Example: An RSS-14 bar code 100123456788902 is transmitted as
]e001100123456788902.
EAN.UCC Composites (RSS, UCC/EAN-128, 2D portion of UPC composite)
0
1
2
3
EAN.UCC Composites (RSS, UCC/EAN-128, 2D portion of UPC composite)
1
According to AIM standards, a UPC with supplemental bar code is transmitted in one of the
following formats:
]E0 (UPC chars) (terminator) ]E2 (supplemental) (terminator) or
]E2 (supplemental) (terminator) ]E0 (UPC chars) (terminator)
In the M2000, however, the format is changed to:
]E0 (UPC chars) ]E2 (supplemental)
A-6
TM
M2000 Series Product Reference Guide
Table A-3. Modifier Characters
No option specified at this time. Always transmit 0. RSS-14 and
RSS-Limited transmit with an Application Identifier "01".
Note: In UCC/EAN-128 emulation mode, RSS is transmitted using
Code 128 rules (i.e., ]C1).
Native mode transmission.
Note: UPC portion of composite is transmitted using UPC rules.
Standard data packet.
Data packet containing the data following an encoded symbol
separator character.
Data packet containing the data following an escape mechanism
character. The data packet does not support the ECI protocol.
Data packet containing the data following an escape mechanism
character. The data packet supports the ECI protocol.
UCC/EAN-128 emulation
Note: UPC portion of composite is transmitted using UPC rules.
Data packet is a UCC/EAN-128 symbol (i.e., data is preceded with
]JC1).
Option
