Synapse Cable Pinouts - Symbol Cyclone M2000 Series Product Reference Manual

Cyclone
Pin
2 RxD
3 TxD
5, 6, 11 Ground
7, 10 +5V / +12V
12 DTR
13 RTS
14 CTS
FERRULE DRAIN

Synapse Cable Pinouts

Table B-8. 6-Pin Male Modular Connector for Synapse Cable
Pin
1
2
3
4
B-8
TM
M2000 Series Product Reference Guide
Table B-7. IBM Sure One, 8-Pin Connector
P/N 25-32470-01, -02
Signal
Serial data receive input. Driven by the serial data transmit
output on the device communicating with the scanner.
Serial data transmit output. Drives the serial data receive input
on the device communicating with the scanner.
Power supply input ground pin and reference for both output
signals. Must be capable of sinking all return current.
Power.
Data Terminal Ready. This signal is hardwired active.
Request-to-send handshaking output line. Used optionally by
the scanner to signal another device that data is available to
send. Used only in conjunction with CTS line.
Clear-to-send handshaking input line. Used optionally by
another device to signal the scanner that it may commence
transmitting data. Used only in conjunction with RTS line.
P/N 25-32463-01, -02
Signal
SYNDATA Synapse-compatible data line. Bi-directional.
SYNCLK Synapse-compatible clock line. Bi-directional.
VCC Power.
GND Power supply ground pin and reference for both output
signals. Must be capable of sinking all return current.
Function
Function
