Canon imagePROGRAF iPF5000 Series Service Manual page 158

Chapter 6
J2702 (Cassette)
Pin Number Signal name
3 GND
4 CST_ENCA
5 SNS_5V
6 CST_ENCB
7 SNS_3V_1
8 GND
9 CST_CAM_SNS
10 SNS_3V_1
11 GND
12 CST_EARLY_SNS
13 SNS_3V_1
14 GND
15 CST_UNIT_SNS
J2703 (Auto feed roll unit)
Pin Number Signal name
1 OPT_5V
2 GND
3 ROLL_CAM_SNS
4 ROLL_PAPER_SNS
5 ROLL_UNIT
6 VM
7 VM
8 /ROLL_SLEEP
9 ROLL_STB
10 ROLL_DAT
11 ROLL_CLK
12 GND
13 GND
J2801 (Feed motor)
Pin Number Signal name
1 LF_OUTB
2 LF_OUTA
J2901 (Purge unit)
Pin Number Signal name
1 PUMP_OUTB
2 PUMP_OUTA
3 GND
4 PUMP_ENCA
5 SNS_5V
6 PUMP_ENCB
7 PUMP_CAM_3V
8 GND
9 PUMP_CAM_SNS_OUT
J3001 (Lift motor/head management sensor)
Pin Number Signal name
1 LIFTOUTCOM
2 LIFT_OUTAP
3 LIFT_OUTAM
4 LIFT_OUTBP
5 LIFT_OUTBM
6 GND
7 FUTO_CLMP
8 FUTO_XLEDON
9 SNS_5V
10 FUTO_XCMP0
11 SNS_3V_1
12 GND
6-6
IN/OUT Function
- GND
IN Cassette encoder output signal A
OUT Power supply (+5V)
IN Cassette encoder output signal B
OUT Power supply (+3.3V)
- GND
Cassette cam sensor output signal
OUT Power supply (+3.3V)
- GND
IN Cassette pick-up sensor output signal
OUT Power supply (+3.3V)
- GND
IN Cassette detection sensor output signal
T-6-14
IN/OUT Function
OUT Power supply (+5V)
- GND
IN Roll cam sensor signal
IN Roll media sensor signal
IN Roll unit detection signal
OUT Power supply (+26V)
OUT Power supply (+26V)
OUT Roll motor driver sleep signal
OUT Roll motor driver strobe signal
OUT Roll motor driver data signal
OUT Roll motor driver clock signal
- GND
- GND
T-6-15
IN/OUT Function
OUT Feed motor drive signal B
OUT Feed motor drive signal A
T-6-16
IN/OUT Function
OUT Pump motor drive signal B
OUT Pump motor drive signal A
- GND
IN Pump encoder output signal A
Power supply (+5V)
IN Pump encoder output signal B
OUT Power supply (+3.3V)
- GND
IN Pump cam sensor output signal
T-6-17
IN/OUT Function
OUT Lift motor Power supply
OUT Lift motor drive signal AP
OUT Lift motor drive signal AM
OUT Lift motor drive signal BP
OUT Lift motor drive signal BM
- GND
OUT Head management sensor unit clamp signal
OUT Head management sensor unit LED ON/OFF signal
Power supply (+5V)
IN Head management sensor unit skew detection signal
OUT Power supply (+3.3V)
- GND
