Procedure After Replacing The Head Management Sensor - Canon imagePROGRAF iPF5000 Series Service Manual

Chapter 4
* After installing the right cover, check that the wire roller has not been disengaged.

4.5.3 Procedure after Replacing the Head Management Sensor

0012-6487
Since the distance between the head management sensor and the carriage unit varies among printers, the optical axis is factory-adjusted to adjust the non-discharging
detection position. When you have replaced the head management sensor or performed assembly/reassembly of surrounding parts that can change the distance be-
tween the head management sensor and the carriage unit, reasjustment is required
Peform the readjustment in the service mode.
Service mode : SERVICE MODE > ADJUST > NOZZLE CHK POS.
