Canon imagePROGRAF iPF5000 Series Service Manual page 157

J2501 (Connect to Spur motor/spur cam sensor/Lift cam sensor/mist fan)
Pin Number Signal name
10 LIFT_CAM_3V
11 GND
12 LIFT_CAM_SNS
J2502 (Suction fan/maintenance cartridge relay PCB/cassette paper detection sensor/Feed roller HP sensor/feed roller encoder)
Pin Number Signal name
1 FAN_VM
2 PLATEN_FAN_LOCK
3 PLATEN_FAN_PWM
4 GND
5 MENT_SDA
6 MENT_SCL
7 GND
8 MENT_3V
9 CST_PAPER_NONE_3V
10 GND
11 CST_PAPER_NONE_SNS
12 LF_HP_3V
13 GND
14 LF_HP_SNS
15 GND
16 LF_ENCA
17 RGV5
18 LF_ENCB
J2601 (Operation panel)
Pin Number Signal name
1 POWER_ON
2 PM_START
3 BUZZER
4 PDODATA
5 +3.3V
6 PDI_DATA
7 GND
8 /PANEL RESET
9 GND
10 PDOPCLK
11 PANEL_5V
12 /PDOCS_L
J2701 (Cutter unit)
Pin Number Signal name
1 OPT_5V
2 GND
3 CUTTER_L_SNS
4 CUTTER_R_SNS
5 CUTTER_POS1_SNS
6 CUTTER_UNIT
7 CUTTER_VM
8 /CUTTER_SLEEP
9 CUTTER_STB
10 CUTTER_DAT
11 CUTTER_CLK
12 CUTTER_ENB
13 CUTTER_PHS
14 GND
J2702 (Cassette)
Pin Number Signal name
1 CST_OUTB
2 CST_OUTA
IN/OUT Function
OUT Power supply (+3.3V)
- GND
IN Lift cam sensor output signal
T-6-10
IN/OUT Function
OUT Power supply (+26V)
IN suction fan lock signal
OUT suction fan duty control signal
- GND
IN/OUT Maintenance cartridge rom control signal (data)
IN/OUT Maintenance cartridge rom control signal (clock)
- GND
Power supply (+3.3V)
OUT Power supply (+3.3V)
- GND
IN Cassette paper detection sensor output signal
OUT Power supply (+3.3V)
- GND
IN Feed roller HP sensor output signal
- GND
IN Feed roller encoder output signal A
OUT Power supply (+5V)
IN Feed roller encoder output signal B
T-6-11
IN/OUT Function
IN Power switch signal
OUT Power supply (+5V)
OUT Buzzer control signal
OUT Panel IC control signal
OUT Power supply (+3.3V)
IN Panel IC data signal
- GND
OUT Panel reset signal
- GND
OUT Panel IC clock signal
OUT Power supply (+5V)
OUT Panel supply chip select signal
T-6-12
IN/OUT Function
OUT Power supply (+5V)
- GND
IN Cutter HP sensor signal
IN Cutter right detection sensor signal
IN Cutter lift sensor signal
IN Cutter unit detection signal
OUT Power supply (+26V)
OUT Cutter motor driver sleep signal
OUT Cutter motor driver strobe signal
OUT Cutter motor driver data signal
OUT Cutter motor driver clock signal
OUT Cutter motor driver enable signal
OUT Cutter motor driver phase signal
- GND
T-6-13
IN/OUT Function
OUT Cassette motor drive signal B
OUT Cassette motor drive signal A
