Interface Cable
USB Interface
EasyCoder PM4i Printer User's Guide (IPL Version)
RS-232
Computerend:Dependsoncomputermodel
Printerend:
ThisprintersupportsUSBv1.1(alsocalledUSB2.0fullspeed).
TousetheUSBinterfaceforprintingfromaPC,youneeda
specialIntermecUSBprinterdriverinstalledinyourPC.
Theprinterisasocalled"self-powereddevice."Werecommend
thatyouonlyconnectoneprintertoeachUSBportonthehost,
eitherdirectlyorviaahub.Otherdevices,likeakeyboardanda
mouse,canbeconnectedtothesamehub.Ifyouneedtoconnect
morethanoneIntermecUSBprintertoahost,youshoulduse
differentUSBports.
UsingaUSBClassA/Bcable,connecttheClassAplugtoyour
PCorhubandtheClassBplugtoyourprinter.
TheUSBinterfaceisessentiallyaone-waycommunication
interfaceandisthusnotrecommendedforprogramming.There
isnocommunicationsetupfortheUSBport.
USB Class A connector. Connect to PC or hub.
Appendix C — Interfaces
