Wall Mounting
The QDSP-1000/1010 comes with two L-brackets for wall mounting. Secure the
L-brackets to the each side of the chassis using the 4 screws.
Refer to figure below for wall mount holes
allows the QDSP-1000/1010 to be mounted with the Front Panel facing in any
orientation, and provides for easy removal of the chassis for repair of maintenance.
Use standard M3 screws to mount the QDSP-1000/1010.
QDSP-1000/ 1010 User's Manual
Figure 7 Secure the L-brackets for wall mounting
Figure 8 Wall mount holes spacing
spacing.
The shape of the screw holes
20
Chapter 2
Wall Mounting
holes
