Power Connection
1.
Connect the supplied AC power cord to the AC power inlet of the AC Power
adapter.
2.
Connect the other end of the AC power cord to a corresponding outlet
3.
Connect and secure the DC power outlet of the AC Power adapter to the DC
power inlet of the QDSP-1000/1010.
Use the power cord suitable for the power supply in your country. Do not
remove or alter the grounding prong on the power cord. In situations where
a two-slot receptacle is present, have it replaced with a properly grounded
three-prong grounding type receptacle.
QDSP-1000/ 1010 User's Manual
Chapter 3
Getting Started
Figure 10 Power connector - DC power inlet
CAUTION
22
Chapter 3
