- Page 1 QutePC-5000 Series 0.6-Liter Box PC with Intel® Haswell / Broadwell ULT Processors User’s Guide...
-
Page 2: Table Of Contents
Anti-theft protection with a Kensington Lock ........22 Chapter 3 AMI BIOS Setup..................23 Overview..................... 23 Main Menu ..................24 Advanced Menu.................. 26 Boot Menu ..................34 Security Menu..................35 Save & Exit Menu ................36 Chapter 4 Driver Installation .................. 38 QutePC-5000 series User’s Manual... -
Page 3: Figures & Tables
Figure 7 Turning on the system ..............20 Figure 8 VESA mounting................21 Figure 9 Use a Kensington lock ..............22 Table 1 QutePC-5000 series product specification ........12 Table 2 BIOS Main Menu ................24 Table 3 BIOS Main Menu ................25 Table 4 Advanced Menu................ -
Page 4: Safety Instructions
Turn off system power, turn off the power supply, and then disconnect the power cord from its source before removing the chassis cover. Turning off the system power switch does not remove power to components. QutePC-5000 series User’s Manual... -
Page 5: When Working Inside A Computer
ESD procedure, which can include wrist straps and smocks, when servicing equipment. You can also take the following steps to prevent damage from electrostatic discharge (ESD): When unpacking a static-sensitive component from its shipping carton, do not QutePC-5000 series User’s Manual... -
Page 6: Instructions For Lithium Battery
(e.g. to the collecting points for disposal of batteries) Voltage Ratings The external power adaptor of the QutePC-5000 series has the following voltage ratings: Input: 100-240 VAC, 50-60 Hz Output: 65W, +19VDC/3.42A output... -
Page 7: Preface
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the QutePC-5000 series User’s Manual... -
Page 8: Maintaining Your Computer
However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an acceptable range. Refer to the “Specifications” section of this user’s guide for QutePC-5000 series User’s Manual... -
Page 9: Power Protection
UPS system. UPS systems range in price from a few hundred dollars to several thousand dollars, with the more expensive unit s allowing you to run larger systems for a QutePC-5000 series User’s Manual... - Page 10 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. QutePC-5000 series User’s Manual...
-
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Overview The QutePC-5000 series is a Box PC with a volume of just 0.6-liter that is ideal for space critical applications. This embedded hardware platform is designed with Intel® Haswell / Broadwell ULT processor which provides with excellent performance. -
Page 12: Product Specifications
Storage: -20°C to 80°C, 0%-90%, non-condensing Dimensions 130 x 39 x 115 mm (WxHxD) Weight 550 g Others Kensington Lock Support Mounting VESA mount, Desktop stand Certifications CE, FCC Class A Table 1 QutePC-5000 series product specification QutePC-5000 series User’s Manual... -
Page 13: System Tour
The WiFi LED will light when the WiFi is on. HDD LED The hard disk LED blinks when data is being written into or read from the HDD. Power Switch The power switch allows powering ON and OFF the system. QutePC-5000 series User’s Manual... -
Page 14: Figure 2 Rear Panel
DVI-D DVI-D is an acronym which means Digital Video Interface Digital. Essentially it is a cable that connects two devices producing an output image on a screen. QutePC-5000 series User’s Manual... - Page 15 Chapter 1 HDMI HDMI connector for display output External power switch The external power switch allows powering ON and OFF the system. Wireless reserved holes for wireless antenna connections. Clear CMOS 1x reset button for clear CMOS. QutePC-5000 series User’s Manual...
-
Page 16: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 130 x 39 x 116 mm (WxHxD) Figure 3 Mechanical Dimensions QutePC-5000 series User’s Manual... -
Page 17: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC Connecting the monitor Connect the DVI-D/ HDMI cable from your display to the DVI-D/ HDMI port. DVI-D HDMI Figure 4 DVI-D / HDMI QutePC-5000 series User’s Manual... -
Page 18: Figure 5 Connecting Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your QutePC-5000 series does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. USB 3.0 USB 2.0 Figure 5 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 19: Figure 6 Rj45 Connector
Chapter 2 Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other end to a hub or switch. RJ45 Figure 6 RJ45 connector QutePC-5000 series User’s Manual... -
Page 20: Figure 7 Turning On The System
Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system External Power Switch On/Off DC Jack Figure 7 Turning on the system QutePC-5000 series User’s Manual... -
Page 21: Mounting Your Pc To A Monitor
To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. The VESA mounting kit is optional. Place the QutePC-5000 series on the VESA mounting bracket and make sure the bracket is hooked with the fins of the system housing. -
Page 22: Anti-Theft Protection With A Kensington Lock
Chapter 2 Anti-theft protection with a Kensington Lock The QutePC-5000 series has a Kensington lock slot for the Kensington MicroSaver. With the Kensington MicroSaver, a sturdy steel cable, you can attach your QutePC-5000 series to a stationary object and protect your PC from theft. -
Page 23: Chapter 3 Ami Bios Setup
It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings. QutePC-5000 series User’s Manual... -
Page 24: Main Menu
F2: Previous Values F3: Optimized Defaults Total Size 4096 MB (DDR3) F4 Save & Exit Frequency 1600 MHz ESC Exit System date [Tue 03/11/2014] System time [14:05:23] Access Level Administrator Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. QutePC-5000 series User’s Manual... -
Page 25: Table 3 Bios Main Menu
F2: Previous Values F3: Optimized Defaults Total Size 4096 MB (DDR3) F4 Save & Exit Frequency 1600 MHz ESC Exit System date [Tue 11/06/2015] System time [14:05:23] Access Level Administrator Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. QutePC-5000 series User’s Manual... -
Page 26: Advanced Menu
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 27: Table 5 Advanced Menu – Display Configuration
320 M , 352 M , 384 M , 416 M , 448 M , 480 M , 512M , 1024M DVMT Total Gfx Mem Options: 128MB, 256MB, MAX IGFX-Boot Type Options: VBIOS Default, DVI, HDMI QutePC-5000 series User’s Manual... -
Page 28: Table 6 Advanced Menu –Cpu Chipset Configuration
EIST Options: Disabled, Enabled Hyper-Threading Options: Disabled, Enabled VT-d Options: Disabled, Enabled Active Processor Cores Options: All, 1 Limit CPUID Maximum Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Intel Virtualization Technology Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 29: Table 7 Advanced Menu –Sata Configuration
Version 2.15.1236. Copyright (C) 2012, American Megatrends, Inc. SATA Controller(s) Options: Disabled, Enabled SATA Mode Selection Options: AHCI SATA Controller Speed Options: Default, Gen 1, Gen 2 , Gen 3 Port 1 (For SATA Port / mSATA Port) Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 30: Table 8 Advanced Menu –Usb Configuration
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. Legacy USB Support Options: Disabled, Enabled, Auto USB3.0 Support Options: Disabled, Enabled xHCI Hand-off Options: Disabled, Enabled EHCI Hand-off Options: Disabled, Enabled USB Mass Storage Driver Support Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 31: Table 9 Advanced Menu –Intel (R) Rapid Start Technology
Enter: Select Current Status Information +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. Security Device Support Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 32: Table 11 Advanced Menu –H/W Monitor
+VIN : +12.000V F4 Save & Exit : +5.089V ESC Exit +3.3V : +3.356V Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc. CPU FAN Configuration FAN Setting Manual Mode (Options: Smart , Manual ) Manual Duty QutePC-5000 series User’s Manual... -
Page 33: Table 12 Power Management Configuration
Options: Power Off, Power On, Last State Power Saving Mode Options: Disabled, EUP Enabled, DeepSX Enabled Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled Watchdog Timer Configuration WDT Function Disabled Options: Disabled, Enabled QutePC-5000 series User’s Manual... -
Page 34: Boot Menu
Options: Disabled, Enabled Boot Option Filter Options: UEFI and Legacy, Legacy only, UEFI only Boot Option # 1 Options: Disabled, IBA GE Slot 00C8 v1410 Network Device BBS Priorities Options: Disabled, IBA GE Slot 00C8 v1410 QutePC-5000 series User’s Manual... -
Page 35: Security Menu
The password length must be in the following range: F2: Previous Values Minimum Length F3: Optimized Defaults Maximum length F4 Save & Exit ESC Exit Administrator Password User Password Version 2.15.1236. Copyright (C) 2012, American Megatrends, Inc. QutePC-5000 series User’s Manual... -
Page 36: Save & Exit Menu
Save Options Enter: Select Save Changes +- Change Opt. Discard Changes F1: General Help Restore Defaults F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1236. Copyright (C) 2012, American Megatrends, Inc. QutePC-5000 series User’s Manual... - Page 37 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. QutePC-5000 series User’s Manual...
-
Page 38: Chapter 4 Driver Installation
You can download the drivers for the QutePC-5000 series from our website and install as instructed there. For other operating systems, please contact us. QutePC-5000 series User’s Manual...
