Summary of Contents for Quanmax QBOX-2600
- Page 1 QBOX-2600 ® Fanless Box PC with Intel Cedarview-D Atom™ D2550 Processor User’s Guide QBOX-2600 User’s Manual...
- Page 2 © 2011 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Chapter 3 AMI BIOS Setup ..................28 Overview ....................28 Main Menu ....................29 Advanced Menu ..................30 Boot Menu ....................39 Security Menu .................... 40 Save & Exit Menu ..................40 Chapter 4 Driver Installation .................. 42 QBOX-2600 User’s Manual... -
Page 4: Figures
Figure 6 RJ45 connector ................23 Figure 7 Com ports ..................24 Figure 8 DIO port ..................25 Figure 9 Turning on the system ..............26 Figure 10 VESA mounting (1) ..............27 Figure 11 VESA mounting (2) ..............27 QBOX-2600 User’s Manual... -
Page 5: Tables
Tables Tables Table 1 QBOX-2600 Specification .............. 16 Table 2 BIOS Main Menu ................29 Table 3 Advanced Menu ................30 Table 4 Advanced Menu – Display Configuration ........31 Table 5 Advanced Menu –Power Management Configuration ....32 Table 6 Advanced Menu –CPU Advanced Configuration ......33 Table 7 Advanced Menu –SATA Configuration ........... -
Page 6: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken;... -
Page 7: When Working Inside A Computer
Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. QBOX-2600 User’s Manual... -
Page 8: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. -
Page 9: Instructions For Lithium Battery
(e.g. to the collecting points for disposal of batteries) Voltage Ratings The external power adaptor of the QBOX-2600 has the following voltage ratings: Input: 100-240 VAC, 50-60 Hz ... -
Page 10: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 11: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 12: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. -
Page 13: Power Protection
Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. QBOX-2600 User’s Manual... - Page 14 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. QBOX-2600 User’s Manual...
-
Page 15: Chapter 1 Introduction
Chapter 1 Chapter 1 Introduction Overview The QBOX-2600 is a fanless Box PC is ideal for space critical applications. This ® embedded hardware platform is designed with Intel Atom™ D2550 Processor which ® provides with excellent performance. The system is supported with Intel NM10 Express chipset, and DDR3 SO-DIMM up to 4GB. -
Page 16: Product Specifications
Storage Temperature: -20°C to 80°C, 0%-90%, non-condensing Dimensions 183.86 x 55.98 x 109.5 mm (W x H x D) Weight 1600 g Mounting Desktop, VESA-mount , Din Rail mount Certifications CE, FCC Class A Table 1 QBOX-2600 Specification QBOX-2600 User’s Manual... -
Page 17: System Tour
The hard disk LED blinks when data is being written into or read from the HDD. Phone Jack Audio Out The green stereo headphone jack is used to connect the system’s audio out signal to amplified speakers or headphones. QBOX-2600 User’s Manual... - Page 18 The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards, mouse devices, cameras, and hard disk drives. USB allows many devices to run simultaneously on a single computer, with some peripheral acting as additional plug-in sites or hubs. QBOX-2600 User’s Manual...
-
Page 19: Figure 2 Rear Panel
PC, always use the supplied power adapter. COM 1 D-Sub 9 pin connector for RS-232/422/485 connection COM 2 D-Sub 9 pin connector for RS-232/422/485 connection Ethernet The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. QBOX-2600 User’s Manual... - Page 20 Wireless reserved holes for wireless antenna connections. Kensington Lock Slot The slot is used for attaching a lock-and-cable apparatus. Locks are generally secured in place with a key or combination lock attached to a rubberized metal cable. QBOX-2600 User’s Manual...
-
Page 21: Mechanical Dimensions
Chapter 1 Mechanical Dimensions Dimension: 183.86 x 55.98 x 109.5 mm (W x H x D) Figure 3 Mechanical Dimensions QBOX-2600 User’s Manual... -
Page 22: Chapter 2 Getting Started
Figure 4 DP/ VGA/ HDMI NOTE When the system reboots without connecting the DP/VGA/HDMI, there might be no image on screen when you insert the DP/VGA/HDMI cable. Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen. QBOX-2600 User’s Manual... -
Page 23: Figure 5 Connect Usb Mouse & Keyboard
Chapter 2 Connect USB mouse & keyboard Your QBOX-2600 does not come with a keyboard and mouse connector, but you can use any USB keyboard or mouse to connect with your computer. USB eSATA Figure 5 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 24: Figure 7 Com Ports
COM 2 COM1 RS-232/422/485 Port 1 D-SUB 9P Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ COM2 RS-232/422/485 Port 2 D-SUB 9P Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ Figure 7 Com ports QBOX-2600 User’s Manual... -
Page 25: Figure 8 Dio Port
DIO port with the pin definition. Digital Input / Output D-SUB 9P Signal Name Digital Input 0 Digital Output 0 Digital Input 1 Digital Output 1 Digital Input 2 Digital Output 2 Digital Input 3 Digital Output 3 Figure 8 DIO port QBOX-2600 User’s Manual... -
Page 26: Figure 9 Turning On The System
Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system DC Jack Power Switch Figure 9 Turning on the system QBOX-2600 User’s Manual... -
Page 27: Mounting Your Pc To A Monitor
To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. Place the QBOX-2600 onto the monitor and secure it with the heat dissipating fins properly on VESA mount kit as shown below. Figure 11 VESA mounting (2) -
Page 28: Chapter 3 Ami Bios Setup
This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact Quanmax. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 29: Main Menu
F1: General Help F2: Previous Values Total Size 1024 MB F3: Optimized Defaults Frequency 1067 MHz (DDR3) F4 Save & Exit System date [Wed 03/07/2012] ESC Exit System time [10:56:23] Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. QBOX-2600 User’s Manual... -
Page 30: Advanced Menu
F3: Optimized Defaults > H/W Monitor F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Onboard LAN Controller Options: Disabled, Enabled Onboard LAN Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled QBOX-2600 User’s Manual... -
Page 31: Table 4 Advanced Menu - Display Configuration
F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Fixed Graphics Memory Size Options: 128MB, 256MB IGFX – Boot Type Options: VBIOS Default, CRT, DP, HDMI QBOX-2600 User’s Manual... -
Page 32: Table 5 Advanced Menu -Power Management Configuration
Options: Power Off, Power On, Last State Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled EUP Power Saving Mode Options: Disabled, Enabled Watchdog Timer Configuration WDT Function ■ Options: Disabled, Enabled QBOX-2600 User’s Manual... -
Page 33: Table 6 Advanced Menu -Cpu Advanced Configuration
SATA Port 2 Not Present Enter: Select +- Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Configure SATA as Options: IDE, AHCI QBOX-2600 User’s Manual... -
Page 34: Table 8 Advanced Menu -Trusted Computing
F4 Save & Exit [Auto] ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Legacy USB Support Options: Disabled, Enabled, Auto EHCI hand-off Options: Disabled, Enabled Mass Storage Device Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM QBOX-2600 User’s Manual... -
Page 35: Table 10 Advanced Menu -Dio Configuration
Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. User Configuration Options: Disabled, Enabled Enabled: DO-1 Options: Output Low, Output High DO-2 Options: Output Low, Output High DO-3 Options: Output Low, Output High DO-4 Options: Output Low, Output High QBOX-2600 User’s Manual... -
Page 36: Table 11 Advanced Menu - Super Io Configuration
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port 1 Type Options: RS232, RS422, RS485 QBOX-2600 User’s Manual... -
Page 37: Table 13 Advanced Menu - Super Io Configuration - Serial Port
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 Serial Port 2 Type Options: RS232, RS422, RS485 QBOX-2600 User’s Manual... -
Page 38: Table 14 Advanced Menu -H/W Monitor
F3: Optimized Defaults +VIN : +19.096V F4 Save & Exit +3.3VSB : +3.360V ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. CPU Warning Temperature Options: Disabled, 80 ºC , 85 ºC, 90 ºC, 95 ºC QBOX-2600 User’s Manual... -
Page 39: Boot Menu
Options: Disabled, Enabled Bootup Numlock State Options: On, Off Boot Option #1 Options: UEFI, SATA PM: Disabled Boot Option #2 Options: UEFI, SATA PM: Disabled Hard Drive BBS Priorities ■ Boot Option #1 Options: UEFI, SATA PM: Disabled QBOX-2600 User’s Manual... -
Page 40: Security Menu
Discard Changes and Reset Enter: Select Save Options +- Change Opt. Save Changes F1: General Help Discard Changes F2: Previous Values F3: Optimized Defaults Restore Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. QBOX-2600 User’s Manual... - Page 41 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. QBOX-2600 User’s Manual...
-
Page 42: Chapter 4 Driver Installation
Chapter 4 Driver Installation If your QBOX-2600 does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate power source, power it up using the power supply and install the desired operating system.
