External Connectors
Rear I/O Panel
Connector
USB
VGA
MS/KB
LAN
COM1
COM2
QDSP-1000/ 1010 User's Manual
Chapter 5
Interface
USB2.0 Connector
VGA Display Connector
PS/2 KB/MS Mini-DIN Connector
Fast/ Gigabit Ethernet Connector
RS-232 Port A DB-9 Connector
RS-232/422/485 Port A DB-9 Connector
Table 3 Rear panel connectors description
Table 4 USB Connector pin definition
28
Function
Chapter 5
