VESA Mounting
The QDSP-1000/1010 comes with a bracket for VESA mounting (75mm and
100mm). First secure the VESA bracket to the VESA mounting holes with the 4
screws then secure the QDSP-1000/1010 to the VESA bracket with 4 screws.
Refer to figure below for the VESA mounting bracket.
QDSP-1000/ 1010 User's Manual
Figure 9 VESA mounting drawing
21
Chapter 2
VESA Mounting
holes
VESA Mounting
bracket
