Architectural Features; Console Port; Lan Port; Reset Switch - Extreme Networks ExtremeWireless AP3935i Installation Manual

Table 1-1 AP3935 LED Indications
LED
2 (Ethernet link state) LAN 1
3 (Ethernet link state) LAN 2
4 (Radio 2 status)
5 (Radio 1 status)

Architectural Features

Console Port

The AP3935 i and e models both include a single RJ45 console port (shown in Figure
for debug purposes. This port enables connection of a console device to the AP through a serial
cable. The console device can be a PC or workstation running a VT‐100 terminal adapter emulator,
or a VT‐100 terminal.

LAN Port

The AP3935
attached directly to a 10/100/1000BaseT LAN segment. This segment must conform to the IEEE
802.3 or 802.3u specifications.
The APs appear as Ethernet nodes and perform a bridging function by moving packets from the
wired LAN to remote workstations on the wireless infrastructure.
The LAN ports also support power over Ethernet PoE 802.3at for full performance; (802.3af for
low performance mode). Refer to "Installation" on page 7, for information on supplying power to
the AP network port from a network device, such as a switch, that provides Power over Ethernet
(PoE).

Reset Switch

The AP3935 provides a Reset Switch to reset or restore factory default configurations. Use a
pointed object to press the switch button through the hole.(See Figure
down the button for less than 5 seconds, the AP performs a software interrupt, causing it to drop
all connections and reset. If you hold the button down for 5 seconds or more, any configuration
changes are removed, and the factory default configuration restores to the AP.
Status
On Green
On Amber
Off
On Green
On Amber
Off
On Green
Off
On Green
Off
has two 10/100/1000BaseT RJ45 LAN ports (see Figure
Description
Indicates a valid 10Mbps or 100Mbps
Ethernet link.
Indicates a valid 1Gbps Ethernet link.
Indicates the link is down.
Indicates a valid 10Mbps or 100Mbps
Ethernet link.
Indicates a valid 1Gbps Ethernet link.
Indicates the link is down.
Indicates Radio 2 is enabled.
Indicates Radio 2 is not on.
Indicates Radio 1 is enabled.
Indicates Radio 1 is not on.
1‐3 on page 3) that can be
1‐3 on page 3). If you hold
ExtremeWireless™ AP3935 Installation Guide 5
1‐3 on page 3)
