Table 1 WS-AP3825 LED Indications (continued)
LED
2 (Ethernet link state) LAN 1
3 (Ethernet link state) LAN 2
4 (Radio 2 status)
5 (Radio 1 status)

Architectural Features

Console Port

The WS-AP3825 i and e models both include a single RJ45 console port (shown in
and Figure 2) for debug purposes. This port enables connection of a console device to the
AP through a serial cable. The console device can be a PC or workstation running a VT-100
terminal adapter emulator, or a VT-100 terminal.

LAN Port

The WS-AP3825 has two 10/100/1000BaseT RJ45 LAN ports (see
attached directly to a 10/100/1000BaseT LAN segment. This segment must conform to the
IEEE 802.3 or 802.3u specifications.
The APs appear as Ethernet nodes and perform a bridging function by moving packets
from the wired LAN to remote workstations on the wireless infrastructure.
The LAN ports also support power over Ethernet (PoE) based on the IEEE 802.3af
standard. Installation
port from a network device, such as a switch, that provides Power over Ethernet (PoE).
Extreme Networks Wireless AP3825 Installation Guide
Status
On Green
On Amber
Off
On Green
On Amber
Off
On Green
Off
On Green
Off
on page 13, for information on supplying power to the AP network
Description
Indicates a valid 100Mbps Ethernet
link.
Indicates a valid 1Gbps Ethernet link.
Indicates the link is down.
Indicates a valid 100Mbps Ethernet
link.
Indicates a valid 1Gbps Ethernet link.
Indicates the link is down.
Indicates Radio 2 is enabled.
Indicates Radio 2 is not on.
Indicates Radio 1 is enabled.
Indicates Radio 1 is not on.
Figure 1) that can be
Introduction
Figure 1
