This installation guide provides an overview and installation instructions for the ExtremeWireless
Access Points AP3935i and AP3935e.
For information about...

About the AP3935i and AP3935e

AP3935 Overview
Architectural Features
About the AP3935i and AP3935e
The AP3935 is designed to extend your Wireless LAN around indoor locations. The AP3935
supports the 802.11ac and 802.11n wireless standards, with full backward compatibility with
legacy 802.11a, and 802.11b/g devices.
The AP3935 interoperates fully with Wireless LANs, including support for VoWLAN, branch
office mode, guest services, RTLS, availability, and mobility features. The operating Temperature:
0 ‐ 50C.
The AP3935i and AP3935e have the following features in common:
• Both support two MIMO 4x4 (up to four 802.11ac spatial streams).
• They provide two single band radios for dual‐band, concurrent operation, optimized for
indoor antenna coverage:
–
–
• They are enclosed in a rectangular, compact case.
• Both models can be mounted on walls and drop/suspended ceilings.
• They provide 80 MHz Bandwidth at 2.4/5 GHz operation (Channel Bonding).
• Power is provided through two Ethernet ports (LAN port). This is the preferred method of
powering the AP on ceiling and wall installations. The AP3935 can also be powered by an
external DC power supply by plugging the supply's input jack into the DC‐In port.
5 GHz (Radio 1) in any of the following modes: IEEE802.11ac, a/b/g and/or n
2.4 GHz (Radio 2) in any of the following modes: IEEE802.11ac, a/b/g and/or n
Introduction
Refer to page...
ExtremeWireless™ AP3935 Installation Guide 1
