Summary of Contents for Extreme Networks ExtremeWireless AP3935e
- Page 1 ExtremeWireless™ AP3935i & AP3935e Installation Guide P/N 9034915 December 2015...
- Page 2 Copyright © 2015 Extreme Networks, Inc. All Rights Reserved. Legal Notices Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Contents About This Guide Who Should Use This Guide ..........................v How to Use This Guide ............................v Related Documents ............................vi Typographical Conventions ..........................vi Getting Help ..............................vii Chapter 1: Introduction About the AP3935i and AP3935e ........................1 AP3935 Overview .............................. 2 AP3935 LED Indicators .......................... - Page 4 Certified External Antennas for AP3935e .................... 24 European Spectrum Usage Rules ....................... 32 Figures ExtremeWireless AP3935i top view....................... 2 ExtremeWireless AP3935e top view ..................... 3 AP3935 bottom view..........................3 AP3935 LEDs ............................4 Kensington Lock slot ..........................6 Attaching Mount Bracket to the Access Point..................8 Attaching the AP3935i on a drop ceiling T-bar rail ................
-
Page 5: About This Guide
About This Guide The guide describes how to mount and connect cables to the ExtremeWireless AP3935 access point. In addition, this guide provides information on the product certifications and national approvals for the AP3935 access point. NOTE This guide does not provide information on configuration of the access points. For information on how to configure the access points, see the ExtremeWireless User Guide. Who Should Use This Guide WARNING Electrical Hazard: Only qualified personnel should install or service this unit. Riesgo Electrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida. -
Page 6: Related Documents
Related Documents The following document can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following location: https://extranet.extremenetworks.com/downloads/ • ExtremeWireless User Guide Typographical Conventions The following typographical conventions and icons are used in this document. Table 3-1 Typographical Conventions blue type Indicates a hypertext link. When reading this document online, click the text in blue to go to the referenced figure, table, or section. Lowercase x Indicates the general use of an alphanumeric character (for example, AP39xx, the x’s indicate a combination of numbers or letters). -
Page 7: Getting Help
Getting Help For additional support related to the AP3935 or this document, contact Extreme Networks using one of the following methods: www.Extreme Networks.com/support/ Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-603-952-5000 For the Extreme Networks Support toll-free number in your country: www.Extreme Networks.com/support/ Before contacting Extreme Networks for technical support, have the following data ready: • Your Extreme Networks service contract number • A description of the failure • A description of any action(s) already taken to resolve the problem (for example, changing mode switches or rebooting the unit) • The serial and revision numbers of all involved Extreme Networks products in the network • A description of your network environment (such as layout, cable type, other relevant environmental information) •... - Page 8 viii...
-
Page 9: Chapter 1: Introduction
Introduction This installation guide provides an overview and installation instructions for the ExtremeWireless Access Points AP3935i and AP3935e. For information about... Refer to page... About the AP3935i and AP3935e AP3935 Overview Architectural Features About the AP3935i and AP3935e The AP3935 is designed to extend your Wireless LAN around indoor locations. The AP3935 supports the 802.11ac and 802.11n wireless standards, with full backward compatibility with legacy 802.11a, and 802.11b/g devices. The AP3935 interoperates fully with Wireless LANs, including support for VoWLAN, branch office mode, guest services, RTLS, availability, and mobility features. The operating temperature: 0 ‐ 50C. The AP3935i and AP3935e have the following features in common: • Both support two MIMO 4x4 (up to four 802.11ac spatial streams). • They provide two single band radios for dual‐band, concurrent operation, optimized for indoor antenna coverage: – 5 GHz (Radio 1) in any of the following modes: IEEE802.11ac, a/b/g and/or n – 2.4 GHz (Radio 2) in any of the following modes: IEEE802.11ac, a/b/g and/or n • They are enclosed in a rectangular, compact case. -
Page 10: Ap3935 Overview
NOTE The AP3935 comes in two models: the AP3935i has 8 internal single-band antennas while the AP3935e has 8 external RSMA connectors for connecting external antennas. Within this document, any reference to AP3935 applies to both models. AP3935 Overview The AP3935 access point is available in two models: •... -
Page 11: Extremewireless Ap3935E Top View
Figure 1-2 ExtremeWireless AP3935e top view Figure 1-3 AP3935 bottom view 1 Reset Button 3 LAN Ethernet Ports 1 and 2 2 Console Port 4 External Power DC 12V ExtremeWireless™ AP3935 Installation Guide 3... -
Page 12: Ap3935 Led Indicators
AP3935 LED Indicators Both models of the AP3935 have the LED indicators, shown in Figure 1‐4 below. The LEDs provide status information, described in Table 1‐1, on the current state of the AP3935. For more information, see the ExtremeWireless User Guide. Figure 1-4 AP3935 LEDs 1 Status 4 Radio 1 (5 GHz) 2 LAN 1 (Ethernet 1) 5 Radio 2 (2.4 GHz) 3 LAN 2 (Ethernet 2) Table 1-1 AP3935 LED Indications Status Description 1 (AP status) On Green... -
Page 13: Architectural Features
Table 1-1 AP3935 LED Indications Status Description 2 (Ethernet link state) LAN 1 On Green Indicates a valid 10Mbps or 100Mbps Ethernet link. On Amber Indicates a valid 1Gbps Ethernet link. Indicates the link is down. 3 (Ethernet link state) LAN 2 On Green Indicates a valid 10Mbps or 100Mbps Ethernet link. -
Page 14: Kensington Lock Slot
Kensington Lock Slot There is a slot for a Kensington lock on the side of the AP (Figure 1‐5). See the Kensington lock documentation for instructions on use of the lock. Figure 1-5 Kensington Lock slot 6 Architectural Features... -
Page 15: Chapter 2: Installation
Installation This chapter provides installation instructions for the ExtremeWireless AP3935 access points and an optional AP power supply. For information about... Refer to page... Unpacking the AP3935 Accessories Access Point Installation Procedures Configuring AP3935e Channel Settings 2-12 Unpacking the AP3935 To unpack the access point: Open the box and remove the packing material protecting the AP. Verify that the carton contains the items listed in Table 2‐1. Table 2-1 AP3935 Package Contents Quantity Item AP3935 Ceiling Mounting bracket Wall mounting screws and plastic anchors AP3935 Quick Reference Guide Hardware bag... -
Page 16: Access Point Installation Procedures
Access Point Installation Procedures WARNING Electrical Hazard: Only qualified personnel should install or service this unit. Riesgo Electrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida. Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden These procedures describe how to attach the AP3935 to a drop ceiling (flat or protruded), and how ... -
Page 17: Mounting The Ap3935 To A Wall
Remove the ceiling panels around the drop ceiling T‐bar rail and verify that the Ethernet cable can reach the AP at the mounting point. Slightly lift the movable T‐bar locking tab to increase the space between the stationary and the movable T‐bar sides of the bracket. Then hook the stationary end of the T‐bar bracket onto the T‐bar, as shown in Figure 2‐2. While holding the AP with one hand, reach the other hand over the T‐bar and grasp both the stationary and movable sides of the bracket. Push the bracket parts together so they both grasp the T‐bar and the locking tab clicks into place. While still holding the AP, rock it back and forth to ensure that it is securely mounted. Figure 2-2 Attaching the AP3935i on a drop ceiling T-bar rail Make a hole through the ceiling panel closest to the power slot on the AP. Run the Ethernet cable through the hole and into an RJ45 LAN port in the recessed connector bay. If necessary, cut the tiles for the cables, attach the cables to the AP, and replace the tiles. Replace the displaced ceiling panels. Mounting the AP3935 to a Wall Screws for attaching the AP to a wall are supplied with the product. Use the following procedure to mount the AP3935 to a flat wall: Determine the spot on the wall to mount the AP. Pick a spot near the ceiling, but in reach of the Ethernet cable and if you are using external power, near a wall power outlet. To mount the AP directly on the wall with two screws, use the provided template and mark the two drill holes on the wall. In drywall, the drill holes should be 6MM to 0.250ʺ in diameter. Drill two holes in the wall to match the center of the two keyhole slots in the back of the AP bracket. Screw the anchors into the holes until they are flush with the wall. Screw the provided mounting screws into the anchors with the head protruding about 5/32” ... -
Page 18: Mounting The Ap Using The Optional Mounting Bracket
Figure 2-3 Mounting the AP3935 to a Flat Wall. Place the back of the AP against the wall with the protruding mounting screw heads fitting through the keyhole slots on the back of the AP. Slide the AP down until the AP rests on the mounting screw heads. When mounting the AP on a wall or flat ceiling, a Kensington lock provides extra stability. NOTE The mounting bracket (30513, WS-MBI-WALL03) is optional when mounting the AP on a wall. If mounting the AP on a flat ceiling, we recommend using the mounting bracket (30513, WS-MBI-WALL03) for added security. -
Page 19: Lan/Console Connections
Use a magnetic screw driver to attach the small screw. Do NOT exceed 12 in‐lbs of torque. Use a Kensington lock for added security (see Figure 1‐5 on page 6). LAN/Console Connections NOTE LAN/Console connectors with shrouds will not fit into the ports. An optional jumper cable may be used or the shroud removed. The AP3935 has 2 LAN ports and a Console port. Power is provided through two Ethernet ports (LAN ports). This is the preferred method of powering the AP on ceiling and wall installations. The AP can be powered in one of the following ways: • Power over Ethernet (PoE) Power is provided through the RJ45 Ethernet port (LAN port) on the top of the AP. This is the preferred method of powering the AP on ceiling and high wall installations. • Power by external power supply Where a PoE‐capable Ethernet connection is unavailable or impractical, an external 12V DC power supply may be ordered separately to power the AP from a standard AC wall outlet. Figure 2-5 3935e Access Point bottom view 1 Reset Button 3 LAN Ethernet Ports 1 and 2... -
Page 20: Configuring Ap3935E Channel Settings
Configuring AP3935e Channel Settings The AP3935e must be installed by a professional installer. Before starting the installation, the installer needs to determine and configure the following: • Determine the Antenna Model • Configure Radio RF Port • Configure Radio Channel • Configure Radio Transmit (Tx) Power Determine the Antenna Model The professional installer needs to determine antenna models and the number of antenna ports for that model. The number of ports can be determined from visual inspection of the antenna or from the antenna model. For information about antenna models, see Certified External Antennas for AP3935e, Table A‐4 on page 24. Configure Radio RF Port The professional installer configures Radio RF ports where antenna ports will be connected. To Configure Radio RF Ports through the ExtremeWireless Assistant Log into the Wireless Assistant. From the top menu, click AP. The Wireless AP screen is displayed. Select APs in the left pane, then in the Wireless AP list, click the Wireless AP whose properties you want to modify. The AP Properties tab displays Wireless AP information. 12 Configuring AP3935e Channel Settings... -
Page 21: Ap Properties For The Ap3935E
Figure 2-6 AP Properties for the AP3935e ExtremeWireless™ AP3935 Installation Guide 13... -
Page 22: Configure Radio Channel
When configuring the AP3935e, click Professional Install. The Professional Install dialog displays to configure the external antennas. Modify the Radio Antenna Type as follows: – If attaching quad port antennas, configure all four RF ports with the same antenna type. – If attaching triple port antennas, configure ports 1, 2, and 3 with the same antenna type and configure port 4 (non‐active port) to No Antenna. – If attaching dual port antennas, configure ports 1 and 2 with the same antenna type and configure ports 3 and 4 (non‐active ports) to No Antenna. – If attaching single port antennas, configure port 1to the selected antenna type and configure ports 2‐4 (non‐active ports) to No Antenna. Modify Radio Attenuation as follows: – Add any attenuation (dBm non‐negative) due to cable loss or attenuator added to the line between AP port and the antenna. – Same attenuator loss is assumed and is required for all 4 ports of the radio except when one or more ports is not connected to the antenna and is properly terminated as describe in next step. – The professional installer is responsible for accurately configuring port Attenuation. Never configure port attenuation higher than the actual attenuation between the AP port and the antenna. Install a terminator (rf 50 Ohm) on all ports where an antenna is not connected. Configure Radio Channel Click APs in the left pane, then in the Wireless AP list, click the Wireless AP whose properties you want to modify. The AP Properties tab displays Wireless AP information. 14 Configuring AP3935e Channel Settings... -
Page 23: Ap3935E Radio 1 Properties: Base Settings
Click the Radio 1 tab. Configure the desired Radio Mode, and Channel Width. Figure 2-7 AP3935e Radio 1 Properties: Base Settings From the Request a New Channel drop‐down menu, select a channel according to the site channel plan, or request the AP to auto select the channel from the channel list set in the Channel Plan setting. ExtremeWireless™ AP3935 Installation Guide 15... -
Page 24: Configure Radio Transmit (Tx) Power
Figure 2-8 AP3935e Radio 1 Properties: Channel Plan setting Repeat the process for Radio 2. Configure Radio Transmit (Tx) Power Based on the configured mode, channel, channel plan, and channel width for the specific antenna, the professional installer must enter the corresponding Transmit Power (Tx Power) for the desired Radio using the Extreme Networks Wireless Assistant. Log into the Wireless Assistant. From the top menu, click AP. The Wireless AP screen is displayed. Click the AP button in the left pane, then in the Wireless AP list, click the Wireless AP whose properties you want to modify. The AP Properties tab displays Wireless AP information. Click the Radio 1 tab. Max Tx Power is automatically determined based on regulatory domain/country, antenna selected, line attenuation configured, channel and certification testing. 16 Configuring AP3935e Channel Settings... -
Page 25: Ap3935E Radio 1 Properties: Max Tx Power Setting
Figure 2-9 AP3935e Radio 1 Properties: Max TX Power setting The professional installer is responsible for accurately configuring port Attenuation. Port attenuation should never be configured higher than the actual attenuation between the AP port and the antenna. Repeat the process for Radio 2. ExtremeWireless™ AP3935 Installation Guide 17... - Page 26 18 Configuring AP3935e Channel Settings...
-
Page 27: Appendix A: Specifications
Specifications This appendix lists the specifications for the AP3935i and AP3935e access points and an external 12V DC power supply. Table A-1 Specifications for the AP3935i and AP3935e Item Specification Enclosure material Metal base, plastic cap Power source PoE 802.3at for full performance; (802.3af for low performance mode) DC power supply. Power consumption 20W (Max.) 17.0W (Average) Outside dimensions (max) Length: 215 mm (8.46”) Width: 215 mm (8.46”) -
Page 28: Internal Antenna Aps
Table A-2 Universal Specifications for an External Power Supply Item Specification Enclosure material Plastic housing AC Input 100-240V DC output Output current (max) Output power (max) Power supply 30512 (part number WS‐PSI12V‐MR2), which includes six regional adapters, is recommended for use with all AP3935 APs. Internal Antenna APs Internal Antenna Access Points The AP3935i is an indoor access with eight integrated internal antennas. The following specifications are for the internal antennas: Table A-3 AP3935i Internal Antennas Gain Model Type Application... -
Page 29: Horizontal Radiation Pattern 2.4 Ghz (Xz Plane)
Horizontal Radiation Pattern 2.4 GHz (XZ Plane) Vertical Radiation Pattern 2.4 GHz (XY Plane) ExtremeWireless™ AP3935 Installation Guide 21... -
Page 30: Vertical Radiation Pattern 2.4 Ghz (Yz Plane)
Vertical Radiation Pattern 2.4 GHz (YZ Plane) Horizontal Radiation Pattern 5 GHz (XZ Plane) 22 Internal Antenna APs... -
Page 31: Vertical Radiation Pattern 5 Ghz (Xy Plane)
Vertical Radiation Pattern 5 GHz (XY Plane) Vertical Radiation Pattern 5 GHz (YZ Plane) ExtremeWireless™ AP3935 Installation Guide 23... -
Page 32: External Antennas
External Antennas Table A‐4 lists the certified external antennas for AP3935e. For more detailed specifications and radiation pattern diagrams, see the ExtremeWireless External Antenna Site Preparation and Installation Guide. NOTE Only certified antennas must be used with the AP3935e Access Point. Table A-4 Certified External Antennas for AP3935e Part No. 2.4G (Short Description) Frequency Band Antenna Type Gain Gain 30702 (WS-AI-DQ05120) 2.4G/5G Sector 30703 (WS-AI-5Q04060) Sector 30704 (WS-AI-2Q05060) -
Page 33: Appendix B: Regulatory Information
Warning Changes or modifications made to the ExtremeWireless AP3935 that are not expressly approved by Extreme Networks could void the user's authority to operate the equipment. Only authorized Extreme Networks service personnel are permitted to service the system. -
Page 34: Usa Conformance Standards
• This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential and business environment. This equipment generates, uses, and radiates radio frequency energy, and if not installed and used in accordance with instructions, may cause harmful interference. However, there is no guarantee that interference will not occur. If this equipment does cause harmful interference, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the transmitting antenna. • Increase the separation between the equipment or devices. • Connect the equipment to an outlet other than the receiverʹs. • Consult a dealer or an experienced radio/TV technician for suggestions. USA Conformance Standards This equipment meets the following conformance standards: Safety • UL 60950‐1 • FCC CFR 47 Part 15, Class B Radio transceiver • CFR 47 Part 15.247, Subpart C • CFR 47 Part 15.407, Subpart E Other • IEEE 802.11ac (5 GHz) • IEEE 802.11b/g (2.4 GHz) • IEEE 802.11n ... -
Page 35: Fcc Rf Radiation Exposure Statement
Extreme Networks-certified antennas. Any changes or modifications to the product not expressly approved by Extreme Networks could void the user's authority to operate this device. For the product available in the USA market, only channels 1 to 11 can be operated. -
Page 36: Canada Conformance Standards
• Users are advised that high power radars are allocated as primary users (meaning they have priority) and can cause interference in the 5250‐5350 MHz and 5470‐5850 MHz bands of LE‐ LAN devices. • For the product available in the Canadian market, only channels 1 to 11 can be operated. Selection of other channels in the 2.4 GHz band is not possible. • Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Ce dispositif est conforme à la norme CNR‐210 dʹIndustrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux conditions suivantes: • Le dispositif ne doit pas produire de brouillage préjudiciable. • Ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. • Ce dispositif est conforme à la norme NMB‐003 edictee par le Industrie Canada. • Les dispositifs fonctionnant dans la bande 5 150‐5 250 MHz sont réservés uniquement pour uneutilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. • Les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.‐à‐d., quʹils ont la priorité) pour les bandes 5250‐5350 MHz et 5470‐5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN‐EL. • Pour le produit disponible sur le marché canadien, seuls les canaux 1 à 11 peuvent être utilisés. Il est impossible de sélectionner d’autres canaux dans la bande de 2.4 GHz. • Conformément à la réglementation dʹIndustrie Canada, le présent émetteur radio peut fonctionner avec une antenne dʹun type et dʹun gain maximal (ou inférieur) approuvé pour lʹémetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à lʹintention des autres utilisateurs, il faut choisir le type dʹantenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas lʹintensité nécessaire à lʹétablissement dʹune communication satisfaisante. -
Page 37: European Community
Directive of the European Union (1999/5/EC). Declaration of Conformity in Languages of the European Community English Hereby, Extreme Networks, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Finnish Valmistaja Extreme Networks vakuuttaa täten että Radio LAN device tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä... -
Page 38: European Conformance Standards
1999/5/CE. Spanish Por medio de la presente Extreme Networks declara que el Radio LAN device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. -
Page 39: Conditions Of Use In The European Community
EMC (Emissions / Immunity) • 2004/108/EC EMC Directive • EN 55011/CISPR 11, Class B, Group 1 ISM • EN 55022/CISPR 22, Class B • EN 55024/CISPR 24, includes IEC/EN 61000‐4‐2,3,4,5,6,11 • EN 61000‐3‐2 and ‐3‐3 (Harmonics and Flicker) • EN 60601‐1‐2 (EMC immunity for medical equipment) • EN 50385 (EMF) • ETSI/EN 301 489‐1 & ‐17 Radio transceiver • R&TTE Directive 1999/5/EC • ETSI/EN 300 328 (2.4 GHz) • ETSI/EN 301 893 (5 GHz) Other • IEEE 802.11ac (5 GHz) • IEEE 802.11b/g (2.4 GHz) • IEEE 802.11n • IEEE 802.3at (PoE) • IEEE 802.3af (PoE) RoHS •... -
Page 40: European Spectrum Usage Rules
CAUTION Please follow the instructions in this user guide to configure the ExtremeWireless AP3935. Each Wireless AP is configured with a default group of settings. There is the ability to change these settings. The user or installer is responsible to ensure that each ExtremeWireless AP3935 is configured properly. -
Page 41: Certifications Of Other Countries
Table B-1 European Spectrum Usage Rules (continued) 5.47-5.725 (GHz) 5.15-5.25 (GHz) 5.25-5.35 (GHz) Channels: 2.4-2.4835 (GHz) Channels: Channels: 100,104,108,112,116, Channels: 1 to 13 Country 36,40,44,48 52,56,60,64 132,136,140 (Except Where Noted) Germany Indoor only Indoor only Indoor or outdoor Indoor or outdoor Greece Indoor only Indoor only... - Page 42 • AS/NZS 4288 (Radio via EU standards) • EN 300 328 (2.4 GHz) • EN 301 893 (5 GHz) • EN 301 489‐1 & ‐17 (RLAN) • IEEE 802.11ac (5 GHz) • IEEE 802.11b/g (2.4 GHz) • IEEE 802.11n • IEEE 802.3at (PoE) • IEEE 802.3af (PoE) RF Safety Distance The antennas used for this transmitter must be installed to provide a separation distance of at least 34 cm from all persons and must not be co‐located or operating in conjunction with another antenna or transmitter. 34 ExtremeWireless AP3935i and AP3935e...
-
Page 43: Figures
Figures ExtremeWireless AP3935i top view....................... 2 ExtremeWireless AP3935e top view ..................... 3 AP3935 bottom view..........................3 AP3935 LEDs ............................4 Kensington Lock slot ..........................6 Attaching Mount Bracket to the Access Point..................8 Attaching the AP3935i on a drop ceiling T-bar rail ................9 Mounting the AP3935 to a Flat Wall. - Page 45 Tables Typographical Conventions ........................vi AP3935 LED Indications........................4 AP3935 Package Contents ........................7 Specifications for the AP3935i and AP3935e ..................19 Universal Specifications for an External Power Supply ............... 20 AP3935i Internal Antennas........................20 Certified External Antennas for AP3935e .................... 24 European Spectrum Usage Rules .......................
