AP3935 Overview

The AP3935 access point is available in two models:
• AP3935i contains eight internal single‐band antennas
• AP3935e contains eight external RSMA connectors for optional external antennas, for greater
range and coverage versatility
Figure
view of the AP3935e.
Figure
of the LAN ports, console port, external power supply connector, and reset switch.The bottom
panel is the same for both models, but there are no external antenna RSMA connectors on the
AP3935i.
Figure
Figure 1-1
2 AP3935 Overview
NOTE
The AP3935 comes in two models: the AP3935i has 8 internal single-band
antennas while the AP3935e has 8 external RSMA connectors for connecting
external antennas. Within this document, any reference to AP3935 applies to
both models.
1‐1 on page 2 shows the top view of the AP3935i and Figure
1‐3 on page 3 shows the bottom view of the AP3935e. The bottom view shows the location
1‐4 on page 4 illustrates the AP3935 LEDs.

ExtremeWireless AP3935i top view

1‐2 on page 3 shows the top
