This appendix lists the specifications for the AP3935i and AP3935e access points and an external
12V DC power supply.
Table A-1 Specifications for the AP3935i and AP3935e
Item
Enclosure material
Power source
Power consumption
Outside dimensions (max)
Antenna (AP3935i only)
Uplink Interface
RoHS compliant
Radio Configuration
Operating temperature

External Power Supplies

AP3935 APs may be powered by IEEE 802.3af compliant PoE cables connected to the Ethernet
ports in the connector bay. This is usually the preferred method of powering for users that plan to
mount the devices on ceilings or high up on walls. You can also power these APs with optional,
certified, external power supplies.
Specification
Metal base, plastic cap
PoE 802.3at for full performance; (802.3af for low
performance mode) DC power supply.
20W (Max.) 17.0W
(Average)
Length: 215 mm (8.46")
Width: 215 mm (8.46")
Thickness (not including mounting bracket):
:
AP3935i 56 mm (2.2")
AP3935e: 57 mm (2.23")
8 ports: 4 (Radio1) ports (5GHz antenna), 4 (Radio 2) ports
(2.4GHz antenna)
GbE Ethernet x1 with PoE
Yes
Dual Band Dual Concurrent 802.11ac and 802.11n
Radio 1 IEEE 802.11ac, 5GHz, 4x4:4 MU-MIMO, 20/40/
80MHz channel (up to 1733 Mbps per radio)
Radio 2 IEEE 802.11n, 2.4GHz, 4x4:4, MCS8, MCS9, 20/
40MHz channel (up to 800 Mbps per radio)
o o o
32 F to 122 F (0 C to +50
ExtremeWireless™ AP3935 Installation Guide 19
A
Specifications
o
C)
