Table A-2 Universal Specifications for an External Power Supply
Item
Enclosure material
AC Input
DC output
Output current (max)
Output power (max)
Power supply 30512 (part number WS‐PSI12V‐MR2), which includes six regional adapters, is
recommended for use with all AP3935 APs.

Internal Antenna APs

Internal Antenna Access Points

The AP3935i is an indoor access with eight integrated internal antennas. The following
specifications are for the internal antennas:
Table A-3 AP3935i Internal Antennas
Model Type
AP3935i
The following radiation patterns apply to the antennas in the AP3935i only. In these diagrams, 0
degree is the APʹs front and +/‐ 180 degree is the APʹs back.
The diagrams show radiation patterns along one horizontal plane (XZ) and two vertical planes
(XY and YZ). The X, Y, and Z axes are defined as follows.
20 Internal Antenna APs
Specification
Plastic housing
100-240V
12V
2A
24W
Application Description
Indoor MIMO, Single-band
Gain
(dBi) Frequency (GHz Connector
5dBi 2.4
6dBi 5
None
None
