Operation

Warning! Class 1M LED product according to IEC/EN 60825-1. Do
not view the light output with optical instruments or any device
that may concentrate the beam.
Ambient temperatures
The Easypix system can be operated at ambient temperatures from 5°
C (41° F) to 40° C (104° F).
Status LEDs on the Easypix Power
Colored LEDs on the Easypix Power indicate current system status.
See Table 4.
Indicator name
LED color
ON
OFF
Blinking
* Do not turn power off during a software upload, or you will damage
software on the Easypix Power.
DMX-controlled operation
When the Easypix Power is set up for DMX-controlled operation, faders
on the DMX controller are used to control color and intensity. The
control method depends on which color control mode the Easypix
Power is set to:
In RGB mode, three channels on the controller are used to control the
intensity of red, green and blue from 0% to 100%.
In HSI mode, three channels on the controller are used to control hue,
saturation and intensity.
Hue is controlled in the following order: Red → Orange →
Amber → Yellow → Green → Cyan → Blue → Indigo → Violet
→ Magenta → Red.
Saturation and Intensity can be varied from 0% to 100%.
Power ON
DMX ON
Green
Green
Power on
DMX OK
No power
No DMX
Table 4: Status LEDs
Program mode
Red
System error or high
temperature
System OK
Software uploading*
29
