4 Setup of the OSD Menu:

4.1 Display Boot-UP Info.

Before installation please check the protocol, baud rate, address and RS485
data cable. Default protocol: PELCO-D, address: 1, baud rate: 2400.
When starting, the PTZ will display the following information:
Once done, the above information will disappear and the user will gain
control over the camera.

4.2 Enter the OSD Menu:

While the camera is in standby condition, call preset 95 ("Call" + 95 + "Enter")
in order to display the main menu. Use the Up/Down direction to select item
or start the configuration. Use the Right key to confirm and left key for exit
the current setting.
PROTOCOL: PELCO P D
BAUD RATE: 2400BPS
CAMERA ID: 001
CAMERA S/N: 0000000001
MODEL: -----------------
VERSION: V1.02
FAN SPEED: 6000RPM
STARTING... ....
Level self-check: Success
Vertical self-check: Success
Camera type: ####
Success
