Provision ISR Z-22IR User Manual page 29

<TITLE>: To set current zone Name, 16-bit can be set up by the number

0-9 and the letters A-Z of any combination
<LEFT LIMIT>: Set the right edge of region <A>

Move the camera left limit position to confirm and return. The position of the
left limit position will now be marked on the menu screen.
<RIGHT LIMIT>: Set the right edge of region (B)

Move the camera right limit position to confirm and return. The position of
the right limit position will now be marked on the menu screen.
<PAN SPEED>

High：20/S
Middle：15/S
Low：6/S
Auto：Do as the camera's proportional P/T speed.
<REMOVE CURRENT>: Delete current zone

<RUN>: Start current zone scan repeatedly before receiving new

command.
Note:
PTZ default tour scan direction clockwise direction starting from the left
limit. If the user finds out the route is wrong, he could call number 82
preset again, when the tour scan run to the critical point, PTZ will scan in
the reverse direction.
CALL PRESET 1 TO BACK
CONFIRM. . . . . .
CALL PRESET 1 TO BACK
CONFIRM. . . . . .
28
