4. Setup of the OSD Menu:

4.1 Display Boot-UP Info.

Before installation please check the protocol, baud rate, address, and RS485
data cable. Default Settings: Protocol: PELCO-D, address: 1, baud rate: 2400.

4.2 Enter the OSD Menu:

While the camera is in standby condition, call preset 95 ("Call" + 95 + "Enter")
in order to display the main menu. Use the Up/Down direction to select the
item or start the configuration. Use the Right key to confirm and left the key
to exit the current setting.
The Main menu as follows:
VERSION: VR210P-306
SIGNAL:AHD PAL
PROTOCOL: PELCO P D
BAUD RATE: 2400
CAMERA ID: 001
TEMP: 36
STATUS:OK
INFORMATION
DOME SETTINGS
MOTION
RESTART
FACTORY DEFAULTS
EXIT
