APPENDIX I: DIP SWITCH SETTING

DIP Switch consists of 8 numbers from 1-8, use 8421 binary cod, max 255
address. When the switch is in the "ON" position, the number from 1-8
corresponding to 1, 2, 4, 8, 32, 64, 128. For example, if you set 1, 3, 5, 7
switch to the "ON" position, the corresponding address will be
1+4+16+64=85, please refer to the blow details.
Sheet 1（1=ON, 0=OFF）
DIP switch K1 ID Switch(number 1-
number 8)
Address
1 2 3 4 5 6 7 8
1 1 0 0 0 0 0 0 0
3 1 1 0 0 0 0 0 0
5 1 0 1 0 0 0 0 0
7 1 1 1 0 0 0 0 0
9 1 0 0 1 0 0 0 0
11 1 1 0 1 0 0 0 0
13 1 0 1 1 0 0 0 0
15 1 1 1 1 0 0 0 0
17 1 0 0 0 1 0 0 0
19 1 1 0 0 1 0 0 0
21 1 0 1 0 1 0 0 0
23 1 1 1 0 1 0 0 0
25 1 0 0 1 1 0 0 0
27 1 1 0 1 1 0 0 0
29 1 0 1 1 1 0 0 0
31 1 1 1 1 1 0 0 0
33 1 0 0 0 0 1 0 0
DIP switch K1 ID Switch(number
number 8)
Address
1 2 3 4 5 6 7 8
2 0 1 0 0 0 0 0 0
4 0 0 1 0 0 0 0 0
6 0 1 1 0 0 0 0 0
8 0 0 0 1 0 0 0 0
10 0 1 0 1 0 0 0 0
12 0 0 1 1 0 0 0 0
14 0 1 1 1 0 0 0 0
16 0 0 0 0 1 0 0 0
18 0 1 0 0 1 0 0 0
20 0 0 1 0 1 0 0 0
22 0 1 1 0 1 0 0 0
24 0 0 0 1 1 0 0 0
26 0 1 0 1 1 0 0 0
28 0 0 1 1 1 0 0 0
30 0 1 1 1 1 0 0 0
32 0 0 0 0 0 1 0 0
34 0 1 0 0 0 1 0 0
