3.4 Output Mode Setting:

(1) Default Settings: AHD + PAL/NTSC

This output can be changed via the controller (Even if the user cannot gain a

video output from the unit due to output incompatibility)

(2) Set your controller/DVR PTZ Settings to the Camera's Default

Communication Settings: Protocol: PELCO-D, address: 1 (Unless user

changed it by the DIP switch configuration), baud rate: 2400.

(3) "Set" the Preferable Preset that matches your required configuration:

Set Preset 85 for AHD + PAL

Set Preset 86 for AHD + NTSC

Set Preset 87 for CVBS + PAL

Set Preset 88 for CVBS + NTSC

Before installation please check the protocol, baud rate, address and RS485

data cable. Default Settings: Protocol: PELCO-D, address: 1, baud rate: 2400.

When starting, the PTZ will display the following information:

PROTOCOL: PELCO P D

BAUD RATE: 2400BPS

CAMERA ID: 001

CAMERA S/N: 0000000001

MODEL: -----------------

VERSION: V1.02

FAN SPEED: 6000RPM

STARTING... ....
