1
(3) When the DIP Switch 9th and 10th are ON, the PTZ can automatically
detected the baud rate 2400, 4800,9600,19200
(4) Hardware Address Setup*: Please refer to Appendix I.
*Please note that the address setting can also be configured via the
software using the camera OSD (Page 11).

3.4 Output Mode Setting:

(1) Default Settings: AHD + PAL/NTSC
This output can be changed via the controller (Even if the user cannot gain a
video output from the unit due to output incompatibility)
(2) Set your controller/DVR PTZ Settings to the Camera's Default
Communication Settings: Protocol: PELCO-D, address: 1 (Unless user
changed it by the DIP switch configuration), baud rate: 2400.
(3) Call the Preferable Preset that matches your required configuration:
Preset 74 for AHD + PAL
Preset 75 for AHD + NTSC
Preset 76 for CVBS + PAL
Preset 77 for CVBS + NTSC

4 Setup of the OSD Menu:

4.1 Display Boot-UP Info.

Before installation please check the protocol, baud rate, address and RS485
data cable. Default Settings: Protocol: PELCO-D, address: 1, baud rate: 2400.
Auto detected 2400、
1
4800、9600、
19200BPS
7
600-1800
