  • Page 1: User Manual

    User Manual Please read this instruction carefully for correct use of the product and preserve it for reference purposes...
  • Page 2 PROVISION-ISR DI-380IPVF User Manual 720P IR Fixed Lens IP Dome Camera For H.264 IP Camera All rights reserved...
  • Page 5 Cautions  Before operation, we strongly advise users to read this manual and keep it properly for using later.  Please use the specified power supply to connect.  Avoid from in correct operation, shock vibration, heavy pressing which can cause damage to product.

  • Page 6: Table Of Contents

    Introduction ....................1 1.1 Package ..................... 1 1.2 Overview ....................1 Installation ...................... 3 2.1 Ceiling Mounting ................... 3 2.2 CMS and IP-Tool Installation ..............4 IE Connection ....................5 3.1 LAN ......................5 3.1.1 Access through IP-Tool .............. 5 3.1.2 Directly access through IE ............
  • Page 7 5.4.6 DDNS Configuration ..............20 5.4.7 RTSP ..................24 5.4.8 UPNP ..................24 5.4.9 Mail Setting ................25 5.4.10 FTP .................... 26 5.5 Advanced Configuration ..............26 5.5.1 User Configuration ..............26 5.5.2 Onvif Configuration ..............28 5.5.3 Security Configuration .............. 28 5.5.4 Configure Backup &...

  • Page 8: Introduction

    1 Introduction This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system more stable and reliable.
  • Page 9 CVBS Video Cable: Connect to monitor. MIC Audio Cable: Connect to microphone. DC 12V Power Cable: DC 12V power input. LAN Network Cable: Connect to internet; PoE power supply supported. IP-CAMERA User Manual - 2...

  • Page 10: Installation

    2 Installation 2.1 Ceiling Mounting Before start, please make sure that the ceiling is strong enough to withstand 3 times the weight of the camera. Part of our products may not support to adjust focus or zoom. If you have such cameras, please skip the steps of the zoom and focus adjustment. Step 1: Loosen the lock screw to disassemble the camera from the mounting base.

  • Page 11: Cms And Ip-Tool Installation

    Step 6: Ajust the Zoom screw and the Focus screw with the screwdriver until you get the optimum image. 2.2 CMS and IP-Tool Installation Find CMS software from CD and then double click “Setup.exe” file to pop up installation wizard. Install the software according to the prompts in the wizard.

  • Page 12: Ie Connection

    3 IE Connection User can connect IP-CAM through LAN or WAN. Here only take IE browser (6.0) for example. The details are as follows. 3.1 LAN In LAN, there are two ways to access IP-CAM： ① Access through IP-Tool； ② Directly Access through IE Browser.
  • Page 13 For example, the network segment of this computer is 192.168.13.57. So, please modify the IP address, Subnet Mask, Gateway of IP-Cam which must be in the same network segment with the computer. After modifying, please input the user name and password and then click “OK”...

  • Page 14: Directly Access Through Ie

    Input User name and password and then click “OK” button to login. Note: User also can use the modified IP address of the IP-Cam. Input the IP address in the IE browser bar and then click “Enter” to access IP-Cam. The default user name is admin. The default password is 123456.

  • Page 15: Wan

    Step 2: Open the IE Browser and input the default address of IP-CAM and confirm. Then the IE browser will download Active X control automatically. Step 3: After downloading Active X control, the login dialog box will pop up as below: Step 4: Input user name and password in the login dialog box and click “OK”...

  • Page 16: Remote Preview

    4 Remote Preview 4.1 Remote Preview After you log in, you will see the following window. The descriptions of the icon on the remote preview interface: People icon Fix size Zoom in Zoom in Zoom out Full screen Start record Playback Snap Enable audio...

  • Page 17: Snap

    After selecting the record date, the record files will be displayed in the record file list box. User can double click a certain record file to playback or check a certain file. Then click Play button to do playback. User can do relating operation according to some buttons in the playback interface.
  • Page 18 Click “Browse” to set saving path; Click “Save” to save pictures to HDD on the computer; Click “Printer setup” to set the printer and print the snap pictures; drag the scroll bar to view all snapped pictures. IP-CAMERA User Manual - 11...

  • Page 19: Remote Configuration

    5 Remote Configuration Functions of remote configurations include: System Configuration, Video Configuration, Alarm Configuration, Network Configuration and Advanced Configuration. You should firstly select the menu on the left, and then setup the relative parameters. When one user configures parameters of a certain device, other users can not setup this device. 5.1 System Configuration The “System configuration”...

  • Page 20: Video Configuration

    2. Select “Modify Time ", user can self-define time. Choose the right "Time Zone" according to user’s location. 3. User can also enable DST and set DST mode and time. 4. User can setup time by select the “Synchronize with NTP Server”. 5.

  • Page 21: Video Stream

    5. Enable auto iris, the image mirror and image overturn function. 6. Press the "Save" button to save the settings. 5.2.2 Video Stream 1. Enter into "Video configuration" "Video Stream" to see a interface as shown below: 2. Select the resolution of the single frame image at the "Resolution" pull down list. 3.

  • Page 22: Alarm Configuration

    Alarm Configuration Alarm configuration includes three submenus: Motion Detection Area, Motion Detection Trigger and Motion Detection Schedule. 5.3.1 Motion Detection Area 1. Enter into “Alarm configuration""Motion Detection Area" to see a interface as shown below: 2. Move the "Sensitivity" scroll bar to setup the motion trace sensitivity. 3.

  • Page 23: Motion Detection Schedule

    below: 2. Check "Enable alarm" check box. Then motion based alarm is activated. 3. Set alarm holding time. 4. Set alarm trigger options. Alarm Out: If selected, this would trigger the external relay output on detecting a motion based alarm. Trigger Snap: If selected, the system will snap images on an alarm and save them in SD card.

  • Page 24: Network Configuration

    Week schedule User could set the alarm time from Monday to Sunday for alarm everyday in one week. Note: The lengthwise means one day of a week; the rank means 24 hours of a day. Mouse clicks on the pane to set the alarm hours. Green means selected area. Blank means unselected area.

  • Page 25: Wired

    2. Input port number for IE access in the "HTTP Port" textbox. 3. Input the port number for audio & video transmission in the "Data Port" textbox. 5.4.2 Wired  1. Enter into "Network Configuration" "Wired" to see a tab shown below: 2.

  • Page 26: Server Configuration

    2. Check “transit enable”. Then save the setting. 3. Input www.upnpicp.com in IE address; download and install Active X. Then a window shows up as below: 4. Input the only device ID of the IP-CAM or user-defined name. And then input user name and password.

  • Page 27: Ip Notify

    Note: DDNS is used to register for a hostname with DDNS username and password. Provision ISR now allows you to use our mint DDNS server in order to create a virtual address for your DVR/NVR/IP-Camera on the internet. Each account is limited to 35 different addresses using your preferred domain name address instead of using IP addresses.
  • Page 28 "Registration" Fill in the registration form, then click "Submit" Fill in the host name you want to apply for and press "Request Domain" (for example "home") If there is no problem with the domain registration you will see the following message: “Your domain was successfully created.”...
  • Page 29 1. Enter into "Network Configuration""DDNS Configuration" tab as below: Note: The steps to band a domain name for video surveillance server are as follows. Firstly, register a user name and a password to log on the website of service supplier, and then apply for a domain name online for the server.
  • Page 30 Step 1: Fill in the blank of IE address with ‘www.dns2p.com’. Step 2: Click to enter the website. Step 3: Click "New User" in the right of homepage to register. For example: User ID is ‘abc’, and password is ‘123456’. The register dialog display as above. Login Step 1: Return to homepage after registering successfully.

  • Page 31: Rtsp

    Note: If the connection fails, press the "INFO" button. Now the system will display: ‘DDNS NONE’. Then you need to check network and information above and try again. 3. Application Connect IP-CAMERA to the Network Client. Step 1: After popping up the login interface, fill in "Server" textbox with ‘*.dns2p.com’ to visit the Network Client of the IP-CAMERA.

  • Page 32: Mail Setting

    pop up. Click “YES” button to see a “Windows Components Wizard” dialog box pop up as shown below. Then press “Next” to continue. After finished the installation of configuring components, the UPnP icons will display. Users can double-click certain icon to connect the remote surveillance login interface through IE.

  • Page 33: Ftp

    5. Receival email address list: add email address into the list 6. Receival email address: receiver’s e-mail address 7. After all parameters setup, user can click “Test your account settings”. If email sent successful, a “Test Successful” window will pop up, if not, users can try other email addresses or check the setting.
  • Page 34 Add user: 1. Clicking "Add" button pops up "Add user" dialog box as shown below: After binding physical address to the IP-CAM, you can access the device on this PC only. If the MAC address was ““00:00:00:00:00:00” which means it can be connected to any computers.

  • Page 35: Onvif Configuration

    5. Input computer’s physical address which is used to access the server in the “User PC MAC” text box. 6. Click “OK” button to modify user’s password and binding MAC address successfully. Delete user: 1. Select the user which needs to delete in the user configuration list box. 2.

  • Page 36: Configure Backup & Restore

    4. Select the MAC address which needs to be deleted from the MAC address list box and click “delete” button to delete that MAC address. 5. Click "save" button to save the above setting. 5.5.4 Configure Backup & Restore Enter into Advanced configurationConfigure Backup & Restore Interface. ...

  • Page 37: Upgrade

    5.5.6 Upgrade Enter into Advanced Configuration—Upgrade interface. 1. Click “Browse” button to select the save path of the upgrade file 2. Click “Upgrade server firmware” button to start upgrading the application program 3. The device will restart automatically 4. After you successfully update the software, click “OK” button to close IE and then re-open IE to connect IP-Cam.

  • Page 38: Mobile Surveillance

    6 Mobile Surveillance This IP-CAM supports mobile surveillance by phones with Windows mobile, iPhone, Android and Blackberry OS. Please check the operation system version of mobile before use; and connect the IP-CAM to Internet. 6.1 Network Configuration  Access device via LAN Step 1: Connect device via wireless router.

  • Page 39: By Phones With Iphone Os

    6.2 By Phones with iPhone OS  Install through Iphone. Step 1: Open App Store software as shown in the figure on the left. Step2: Search “Provision Cam” and click “Free” button as shown in the figure on the right. Step 3: Click “Install App”...
  • Page 40  "Provision Cam" Instruction 1. Login Step 1: Choose network type. There are two network connection ways: 3G/3G +WIFI, enhanced video quality. This network supports main stream and sub stream. The real-time image will be displayed by using sub stream. 3G, normal video quality compared to the former network type.
  • Page 41 information, device information, network information, etc. ：Server list button. Click this button to add server list. ：Help button. Help you know about the use of this software quickly. ：CMS button. Make you preview the live image of multi-devices. ：Log off button. Click this button to return to the login interface. ：Screen mode button.
  • Page 42 Channel indicator instruction: ：Video loss ： Schedule recording ：Others ：Sensor alarm ：Motion alarm ：Motion /sensor alarm based recording or manual recording Server list Click button to pop up the following picture.  Add device: Click “Add” button in the top right corner to pop up a dialog box as shown in the following left picture.
  • Page 43 Click “Screen mode” button to select channel as shown in Fig 1. When there is video playing in a screen, you can switch the channel by long pressing the screen as shown in Fig 2. When no video is playing in a screen, click this screen to choose channel as shown in Fig 3.
  • Page 44 Fig 4 Fig 5 CMS Function This function makes multi-device managements and preview come true. Step 1: Click to enable CMS function. When this icon turns green, it means this function is enabled. Step 2: Click to choose channel as shown in the right picture.
  • Page 45 Then click button to play. Only one favorite group can be collected. ：Color means the channel or group has been collected. Grey means the channel or group isn’t collected. Playback Interface Click “Playback” button to enter the playback interface. Then click “Search”...

  • Page 46: By Phones With Android

    By Phones with Android Software Installation Step 1: Run “Play Store” (or Google market) program. Step 2: Search “Provision Cam”. Step 3: Press “Install” button. Step 4: Install the software subject to the notes. Once the downloading is done, the software will install automatically Login Menu Step 1: Configure the network of your device and mobile phone.
  • Page 47 Step 3: Input the account and password of your device. The default account name is admin and the default password is 123456. Step 4: Check “Remember Server” to save Snap the setting. When you login next time, you Record can click button to select this server for quick access.
  • Page 48 Record Playback: Click “Playback” in the main menu interface to enter playback interface. Then choose the channel you want to playback. This will take you to see the record file. Click this file to play. Pause/Play Stop Forward Backward Server List: In the main menu interface, click “Server list”...
  • Page 49 Favorite Channel: Check the favorite channels and click “Save” button to save these channels. Then go into live interface and click button to play these favorite channels. Storage: Setup the relevant parameters of mobile video. Information View: view the DVR/NVR basic information as shown in the picture on the right.

  • Page 50: Ip-Tool

    7 IP-Tool Updating through IP-Tool Note: Do not cut off power supply and internet when updating. If the device is unable to start because of the failure of upgrade, it needs to retrofit. Acquire the IP-Tool from the supplier and then double click the IP-Tool icon to run this software.
  • Page 51 Modify IP address and click OK button to exit the dialog box. After that, IP-Tool will display the new IP address.  Upgrade Software Select the device; right click “Update software”. Click “Update” to start upgrading，the progress bar will display as below. When upgrading, please do not disconnect PC and the device and make sure the power is on.
  • Page 52 Input the relevant information and click “Browse” button to choose your update file. After that, click “Update Kernel” button to start updating. When upgrading, do not disconnect PC to device and make sure the power is on. The update progress bar will display as below: After finishing upgrading, a message box will pop up.
  • Page 53 & & & 8 Q & A 1. Q: How to find my password if I forget it? A：Use the IP-Tool. Run the IP-Tool and right click the camera information to choose “Set Factory Attribute”. Default IP: 192.168.226.201. User name: admin Password: 123456 2.
  • Page 54 & & & Fig 4-1 Fig 4-2 ④ then click ok to finish setup. b. Other plug-ins or anti-virus blocks ActiveX. Please uninstall or close them. 5. Q：No sound can be heard, why? A：Without connect audio input device. Please connect and try again. B: Without enable audio function at the corresponding channel.

  • Page 55: Specification

    9 Specification Model DI-380IPVF Image Sensor Sony Exmor IMX138 1/3" CMOS Effective Pixels 1280×1024 Electronic Shutter 1/25s ~ 1/100000s Day & Night Min. Illumination 0lux (IR ON) Audio compression G711A Audio Communication One Way Audio AWB, AES, AGC Adjustable Exposure Mode (Auto / Manual)
  • Page 56 Notes: IP-CAMERA User Manual - 49...
  • Page 57 IP-CAMERA User Manual - 50...
