Configuration Interface

LOCAL TERMINAL
CONNECTOR
ATLAS 360 Power Supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
ATLAS 160 and 260 Power Supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
ATLAS 360 Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
ATLAS 160 and 260 Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT

Environmental Specifications

AMBIENT TEMPERATURE
RELATIVE HUMIDITY
V.24 9.600-8-N-1-without flow control.
RJ45 female, on the rear panel of the device.
100-240V AC
1 A
50-60 Hz
100 VA
100-240V AC
1 A
50-60 Hz
100 VA
Box to be assembled in a 1U high Rack
483 with rackmount bracket x 395 x 44 mm
444 without rackmount bracket x 395 x 44 mm
4,0 Kg
Box to be assembled in a 1U high Rack
483 with rackmount bracket x 272 x 44 mm
444 without rackmount bracket x 272 x 44 mm
3,250 Kg
ON: 5º to 45ºC.
ON: 8% to 85%.
ATLAS X60
Appendix
II-20
OFF: -20º to 60ºC.
OFF: 5% to 90%.
Doc. Dm695-I
Rev. 1.0
