I - 4. Programming the microswitches

ATLAS X60
The
used for maintenance and test tasks. To access these you need to carry out the
following steps:
•
Switch off the device using the ON/OFF switch.
•
Using a screwdriver, open the device.
•
Have the device facing you (where the LEDs are located). In this
position, the block of microswitches can be seen in the upper left hand
corner on the motherboard, next to the box ventilators.
In this case, they are only used to load the default configuration. These switches
should not be handled by the user except to establish the default configurations.
So the device operates correctly, all the microswitches must be in the
OFF position.

I - 4.1.1. Procedure to ignore the configuration

This procedure is applied if you have to discard the whole configuration of the
device, for example, if you cannot remember the password.
The procedure is as follows:
•
Turn off the device through the ON/OFF switch.
•
Open the device.
•
Using a screwdriver move microswitch '5' to the ON position.
•
Close the device.
•
Turn the device on with the ON/OFF switch.
When the device is switched on, a message similar to the one shown below will
appear on the configuration console:
**************************************************
******************* Router Teldat ****************
**************************************************
BIOS CODE DUMP...................
BIOS DATA DUMP....
End of BIOS dump
Boot-stack used: 0x000007A0
Boot-stack free: 0x00001860
====================================================================
BIOS TELDAT
====================================================================
FLASH BIOS CODE VERSION: 01.04
Current date: Dec 05 2007, Wednesday
router has a block of 8 available microswitches which are
Nov 26 2007 12:29:48
Current time: 17:42:14
ATLAS X60
Installation
I-10
(c)Teldat
L0
Doc. Dm695-I
Rev. 1.0
