GEX Optic connector:
-Left: link and activity detection
OFF:
RED:
-Right: SFP present
OFF:
RED:
Metallic connector:
-Left:
ORANGE:
GREEN:
-Right:
YELLOW:
OFF:
There is no link.
Link detected. Flashing depends on the activity.
SFP not present.
SFP present.
10Mbps. Flashing depends on the activity.
100Mbps. Flashing depends on the activity.
1000Mbps. Flashing depends on the activity.
Both off means the link has not been detected.
