Repeater List Programming; Repeater Name Programming; Repeater Call Sign Programming - Icom IC-9100 Instruction Manual

7
DV MODE PROGRAMMING
1.
q Push [DV DR] to select the DV mode.
w Push [MENU] one or more times to display the "M3"
screen (Menu 3).
the "D1" screen.
M3
CS C D
When the "M3" screen is selected.
e Push [DSET](F-5) to display the "DSET" screen.
DSET
r Push [RP-L](F-4) to display the "RP-L" screen (Re-
peater list).
RP–L R e p e a t e r
t Push [ADD](F-3) to display the "NAME" item (Re-
peater name).
N A M E :
RP–L
Ù
After programming, push [MENU] to display
gramming and return to the "RP-L" screen (Re-
peater list), or push [NO](F-5) to keep program-
ming and return to the previous screen which
was selected before pushing [MENU].
2.
y Push [EDT](F-4) to enter the repeater name pro-
gramming mode.
N A M E :
RP–L
A B C
u Push [ABC](F-1) one or more times to select the
desired character type.
ABC
abc
etc
89
ush [MENU] once or twice to select
R > C S U R DSET
T X M R P — L S E T
L i s t
C L R A D D E D T
Ú
E D T
Blinks
D E L S P C
A to Z
a to z
" ' ` ^ + –
< > ( ) [ ] { } ¦ _ ¯ @
i Rotate [MAIN DIAL] to select the first character or
symbol to input.
When inputting numbers or a decimal point, push
the appropriate keypad key.
bol or number.
beep sounds. If you want to reprogram, push [Ω](F-2) or
[≈](F-3) to select a character, then push [DEL](F-4) to
delete it.
o Push [Ω](F-2) to move the cursor backward, or push
[≈](F-3) to move the cursor forward.
!0 Repeat steps u through i to program a name of
up to 9 characters.
!1 Push [MENU] to save the name.
3.
!2 Push [Z](F-2) to display the "CS" item (Repeater
Call Sign).
!3 Push [EDT](F-4) to enter the repeater call sign pro-
gramming mode.
C S
RP–L
-
!4 Rotate [MAIN DIAL] to select the first character or
symbol ('/' only) to input.
When inputting numbers, push the appropriate key-
pad key.
bol or number.
beep sounds. If you want to reprogram, push [Ω](F-2) or
[≈](F-3) to select a character, then push [DEL](F-4) to
delete it.
!5 Push [Ω](F-2) to move the cursor backward, or push
[≈](F-3) to move the cursor forward.
!6 Repeat steps !4 through !5 to program a repeater
call sign of up to 8 characters.
!7 Push [MENU] to save the call sign.
RP–L C S
Ù Ú
Be sure to add a letter after a repeater call sign,
as the repeater node (port), according to the re-
peater frequency, as shown below. Note that
Japanese repeater node letters are different.
Cross band operation between different nodes in
the same repeater area can be made.
programmed, an error
Blinks
:
D E L S P C
programmed, an error
: JP3YHH B
E D T
-
-
