Dv Set Mode Description - Icom IC-9100 Instruction Manual

The DV Set mode is used for programming infrequently
changed values or functions in the DV mode.
D DV
q In the DV mode, push [MENU] one or more times to
display the "M3" screen (Menu 3).
ush [MENU] once or twice to select
the "D1" screen.
w Push [DSET](F-5) to display the "DSET" screen.
e Push [SET](F-5) to enter the DV Set mode.
r Push [Y](F-1) or [Z](F-2) to select the desired
item.
t Rotate [MAIN DIAL] to select the desired option.
[F-3] for 1 second to reset to the default set-
ting, if desired.
y Push [MENU] to save, and return to the "DSET"
screen.
1.
Turn the Standby beep function ON or OFF.
This function sounds a beep when the other station
stops transmitting.
If the call was sent to your own call sign, the
beep has a higher pitch.
2.
Turn the automatic reply function ON or OFF.
This function automatically replies to a call addressed
to your own call sign, even if you are away from the
transceiver.
This function is automatically turned OFF after you
push [PTT] (microphone) or [TRANSMIT].
call with your own call sign.
3.
For low-speed data communication, select whether to
transmit the input data manually or automatically.
manually transmit the input data.
[DATA1] jack, the transceiver automatically
transmits it.
DV MODE OPERATION
[ ] [ ] [DSET]/[SET]
[MENU]
Displays the DV Set mode
item name and number
SET
Standby Beep
1
Select the item Reset to the default
setting
4.
Select the RX monitoring mode by holding down [XFC]
while in the DV mode.
Monitors in the DV mode or FM mode, de-
pending on the received signal.
5.
Turn the digital repeater setting function ON or OFF.
When accessing a repeater that has a call sign dif-
ferent than the transceiver's "R1" setting, this function
reads the repeater's downlink signal and automatically
sets the correct repeater call sign into "R1."
6.
Turn the RX call sign automatic write function ON or
OFF.
When receiving a call addressed to your own call sign,
this function automatically sets the call sign of the call-
ing station into "UR."
While in the DR mode, this function is disabled.
station into "UR."
8
[MAIN DIAL]
Displays the option
O N – 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
118
