Digital Squelch Functions - Icom IC-9100 Instruction Manual

The digital squelch opens only when receiving a sig-
nal addressed to your own call sign, or a signal that
for calls from others.
Use digital code squelch function when com-
municating with two or more stations, because the
digital call sign squelch function opens only when
receiving a signal addressed to your own call sign.
Thus the digital call sign squelch function can be
used when communicating with only one station.
q Select the desired frequency band. (p. 35)
w In the DV mode, push [MENU] one or more times to
display the "M1" screen (Menu 1).
ush [MENU] once or twice to select
the "D2" screen.
and the DR mode.
e Push [DSQ](F-4) one or more times to turn ON the
digital call sign squelch or digital code squelch.
ON.
When digital call sign squelch is turned ON in step
e, skip steps r and t, and go to step y.
r When digital code squelch is turned ON in step e,
hold down [DSQ](F-4) for 1 second to display the
"DSQ" screen. And rotate [MAIN DIAL] to select the
desired code between 00 and 99.
ting, if desired.
t Push [MENU] to return to the "M1" screen (Menu
1).
y When the received signal includes a matching call
sign/code, the squelch opens and the signal can be
heard.
match, digital call sign/digital code squelch does not
the "D2" screen.
[MENU]
M1
A G C D U P
-
M1
A G C D U P
DSQ D i g i t a l C o d e
"DSQ" screen (Digital code setting)
DV MODE OPERATION
[DSQ]
[MAIN DIAL]
Appears
A F C D S Q S C P
Appears
A F C D S Q S C P
0 0
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
