DV MODE OPERATION

The IC-9100 can be operated in the digital voice mode,
including low-speed data operation, for both transmit
and receive. It can also be connected to a GPS re-
ceiver* to transmit/receive position data.
* Compatible with an RS-232 output/NMEA format/
4800bps/9600 bps
Set the desired
be used for DV operation, as described below.
sign in the "CS" screen (Call Sign).
q Push [DV DR] to select the DV mode.
w Push [MENU] one or more times to display the "M3"
screen (Menu 3).
the "D1" screen.
e Push [CS](F-1) to display the "CS" screen (Call
Sign).
the name.
r Push [Z](F-1) one or more times to display the
t Rotate [MAIN DIAL] to select the desired call sign.
UR : "CQCQCQ," individual station call signs
(U01–U99) or destination repeater call
1
signs* is selected.
lected.
R2 : "NOT USE "*
sign is selected.
or [GRP](F-5)*
"R1" or "R2" is displayed. See the right column for de-
tails of the repeater call sign group selection.
y Push [SET](F-4) to set the selected call sign to be
used for DV operation.
u Repeat steps r to y to set the other call signs.
i Push [Z](F-1) one or more times to return to the
"CS" screen.
peater name or the repeater call sign by pushing
[NAME](F-4) in the R1 and R2 screens.
1
* '/' is displayed in front of the repeater call sign. The
repeater call sign with '/' is used for the gateway CQ
calling.
2
* For an area (local) repeater communication only
(Link repeater is not used.)
3
* [GRP](F-5) is not used in the DR mode.
93
call signs to
ush [MENU] once or twice to select
2
or a link/gateway repeater call
3
makes it more convenient when "UR,"
The IC-9100 has a Time-Out Timer function for digi-
tal repeater operation. The timer limits a continuous
transmission to approximately 10 minutes. Warning
beeps will sound approximately 30 seconds before
time-out and then again immediately before time-out.
Be sure to turn ON the function before operating in
the digital mode. (p. 162)
