7.
This "User Band Edge" item appears only when "ON
Edge Beep" item. (p. 161)
the "Band Edge Beep" item, you can program a total
of 30 band edge frequencies in this item. See page 42
for programming details.
8.
Set a desired beep frequency for the MAIN Band to
between 500 Hz and 2000 Hz in 10 Hz steps.
item. (p. 161)
9.
Set a desired beep frequency for the SUB Band to be-
tween 500 Hz and 2000 Hz in 10 Hz steps.
item. (p. 161)
10.
Set the [RF/SQL] control operation.
squelch control in AM, FM and DV.
trol.
or an
an S-meter squelch in SSB, CW,
AM and DV.
11.
Turn the Meter Peak Hold function ON or OFF.
When this function is set to ON, the peak level of a re-
ceived signal strength or the output power is displayed
for approximately 0.5 seconds.
12.
Turn the FM and DV center error detection ON or
OFF.
When an off-frequency signal is received, the MAIN
and SUB Band's TX/RX indicators blink.
the "Beep Level"
the "Beep Level"
s as a squelch con-
s as a noise squelch
as
,
13.
To prevent a prolonged transmission, the transceiver
has a Time-Out Timer function.
If a continuous transmission exceeds the set period,
the transmission will be cut off.
Set the time period to 3, 5, 10, 20 or 30 minutes, or
turn OFF the Time-Out Timer function.
14.
Turn the PTT Lock function ON or OFF.
To prevent accidental transmissions, this function in-
hibits transmitting, when turned ON.
15.
Turn the Quick Split function ON or OFF.
When this item is set to ON, hold down [SPLIT] for 1
second to shift the transmit frequency from the receive
frequency, according to the "SPLIT Offset" option as
described below. See page 83 for details.
16.
Set the offset* for the quick split function.
*The difference between transmit and receive frequencies.
The frequency offset can be set to between –9.999
MHz and +9.999 MHz in 1 kHz steps.
17. SPLIT LOCK
Turn the Split Lock function ON or OFF.
When this item is set to ON, you can use [MAIN DIAL]
to adjust the transmit frequency while holding down
[XFC], even while the Dial Lock function is enabled.
See pages 82, 83 for split frequency operation de-
tails.
14
SET MODE
162
